ABB Tmax XT Molded Case Circuit Breaker 3-Pole 160A, Breaking Capacity 85 kA, Fixed Mount 1SDA068269R1 XT3S 250 TMG 160A FF

ABB 1SDA068269R1 XT3S 250 TMG 160A FF Molded Case Circuit Breaker is a high-performance, 3-pole MCCB engineered for industrial and commercial electrical protection applications. Rated for 160A current and capable of interrupting short circuits up to 85 kA, it ensures robust and reliable safeguarding of electrical circuits.

This circuit breaker features a fixed mount design and front terminal connections, facilitating straightforward installation and secure wiring in switchgear or panel boards. Its thermomagnetic tripping mechanism (TMG type) combines thermal and magnetic principles to protect circuits from overloads and short circuits effectively.

With rated AC voltage of 690 V and DC voltage of 500 V, this breaker offers versatile use across various power systems. The device complies with key international standards, including CE, IEC, and RoHS, reflecting its safety and environmental credentials.

The physical dimensions of 150 mm height, 105 mm width, and 70 mm depth allow for an efficient panel footprint while maintaining accessibility. The lever reset actuator provides ease of resetting operations after fault clearance.

Manufactured in Italy, the product is designed for disassembly enhancing repairability and recyclability, aligning with sustainable industrial practices. It supports rated frequencies of 50/60 Hz and withstands impulse voltages up to 8 kV, ensuring durability against transient electrical surges.

This ABB MCCB is ideal for applications in electrical distribution panels within industrial plants, manufacturing facilities, commercial buildings, and automation systems requiring dependable circuit protection with ease of maintenance.

The circuit breaker features a fixed mount type for secure installation. It supports a rated AC voltage of 690 V and DC voltage of 500 V. Equipped with thermomagnetic TMG tripping mechanism ensuring precise circuit protection.

Compact unit dimensions: 150mm height, 105mm width, and 70mm depth. Designed with front fixed terminals for ease of wiring and maintenance. Incorporates a lever reset actuator type for quick resetting after trips. Meets CE, IEC, and RoHS standards for safety and sustainability compliance.

Rated frequency is 50/60 Hz with rated impulse withstand voltage of 8 kV. Manufactured in Italy and designed for disassembly to support environmental considerations.
