Clifford & Snell YA30 Series Electronic Sounder Wall Mount, IP66, 230V AC, 100dB, 32 Tones 204296

Free Delivery in India | Lowest Global Shipping Charges

Clifford & Snell YA30 Series Electronic Sounder Wall Mount, IP66, 230V AC, 100dB, 32 Tones 204296

Name: Clifford & Snell YA30 Series Electronic Sounder Wall Mount, IP66, 230V AC, 100dB, 32 Tones 204296
Brand: Clifford & Snell
SKU: 171712
Price: 156.1 USD
Availability: InStock



Category Electronic Sounder Brand Clifford & Snell Condition New

Specifications

Country of Origin	United Kingdom
Diameter	89mm
Brand	Clifford & Snell
Model	204296
IP Rating	IP66
Mount Type	Wall
Housing Material	ABS FR UL95 5VB
Series	YA30
Maximum Operating Temperature	70°C
Current Type	AC
Current consumption	20mA
Minimum Operating Temperature	-35°C
Standards/Approvals	CE Certified EN54-3 UKCA
Maximum Supply Voltage	230V ac
Housing Colour	Red
Tone Type	Alarm
Minimum Sound Level	18dB
Sound Level at 1m	100dB
Maximum Sound Level	100dB
Number of Tones	32
Base Length	89mm
Base Width	85mm

Key Features

The unit has an IP66 rating, offering full protection against dust and low-pressure water jets.
The sounder features a maximum sound level of 100dB at 1m, ideal for noisy environments.
The device supports 32 selectable alarm tones via a 5-way DIL switch for versatile signalling.
Constructed with fire-resistant ABS FR UL95 5VB housing and stainless steel fixings for durability.
The wall mount design ensures easy and secure installation with corrosion-resistant fittings.
It operates reliably between temperatures of -35°C to 70°C for a wide range of industrial conditions.
The red housings provide clear visual alerting for emergency signalling applications.
Compliant with CE Certified EN54-3 UKCA standards for safety signaling devices.

Product Description

Clifford & Snell 204296 YA30 Series Electronic Sounder Wall Mount provides industrial-grade signaling with robust features to ensure enhanced workplace safety in demanding environments. This electronic sounder operates at 230V AC and produces loud 100dB sound levels at 1 meter distance, making it effective for alerting personnel in large or noisy industrial areas.

Featuring an IP66 ingress protection rating, the sounder is fully resistant to dust ingress and able to withstand low-pressure water jets, suitable for harsh indoor and outdoor conditions. Its red ABS FR UL95 5VB housing is fire-resistant and highly durable, complemented by corrosion-resistant stainless steel fixings for secure wall mounting.

The YA30 Series supports 32 selectable alarm tones, configurable easily using a five-way DIL switch, allowing customization to suit specific industrial alert requirements. It functions as a two-stage alarm device, capable of delivering initial hazard warnings and subsequent evacuation alerts for complex safety systems.

Operating performance is reliable across a temperature range of -35°C to 70°C. The sounder complies with CE Certified EN54-3 and UKCA standards, ensuring adherence to recognized safety and performance criteria for fire and safety signaling equipment.

The sounder's current consumption is 20mA, optimized for standard AC 230V supplies. Compact dimensions (89mm diameter, 89mm base length, 85mm base width) facilitate flexible installation in various industrial and commercial settings.

Its bright red color housing serves as a distinct visual indicator for emergency signaling devices.

Common applications include power plant safety systems, government building alert systems, fire alarm signaling, and process control environments where reliable acoustic alarms are critical. This sounder is designed to serve demanding industrial, commercial, and institutional safety needs with robust construction and reliable performance.
