SICK IQ40-40NPSKC0K Block Inductive Proximity Sensor PNP 30V DC 200mA 40mm Detection Range

SICK IQ40-40NPSKC0K is a block-style inductive proximity sensor designed for industrial automation and control applications. It features a robust plastic housing with dimensions 40 mm width, 40 mm depth, and 66 mm length, enabling compact and versatile installation.

The sensor operates on a DC 3-/4-wire electrical configuration with a maximum supply voltage of 30 V DC and provides a PNP output type with a switching current of 200 mA. Its sensing range extends up to 40 mm for reliable metal detection in demanding environments.

The enclosure is rated IP67, IP68, and IP69K, providing resistance to dust, water, and high-pressure washdown conditions. The device supports operation across a broad temperature range from -25 °C to +85 °C ensuring stable performance under harsh conditions.

Installation is simplified with a push-lock mounting system that allows mounting without tools within seconds. The sensor head is rotatable in five directions to adapt to various application requirements. Four corner LEDs provide clear indication of sensor status from any viewing angle.

Typical use cases include presence detection of press tools, positioning of car bodies in rework stations, skid detection at lift exits, rack identification, end position detection on cranes and conveyors, and wear detection on conveyor belt clamps. The long service life and resilient design make it suitable for continuous use in industrial automation, manufacturing, and material handling processes.

Compact block design with wide sensing range up to 40 mm. Push-lock mounting for tool-free installation and fast replacement. Robust plastic housing with IP69K protection rating for harsh environments. Wide operating temperature range from -25 °C to 85 °C ensures reliable function.

Four corner LEDs for clear sensor operation status indication. PNP switching output with 200 mA current and 100 Hz switching frequency. Applications cover presence detection, positioning, and monitoring in automation.

This sensor is part of the SICK IQ40 series, recognized for its ease of installation, reliability, and adaptability in industrial automation environments. The product is manufactured in Malaysia and adheres to UL standards (UL File No. E348498).
