HARTING DIN 41612 64 Way 2.54 mm Pitch, Through Hole Mount, Type C/2, Solder Termination Class C2, 2 Row Male 09721646903

Free Delivery in India | Lowest Global Shipping Charges

HARTING DIN 41612 64 Way 2.54 mm Pitch, Through Hole Mount, Type C/2, Solder Termination Class C2, 2 Row Male 09721646903

Name: HARTING DIN 41612 64 Way 2.54 mm Pitch, Through Hole Mount, Type C/2, Solder Termination Class C2, 2 Row Male 09721646903
Brand: HARTING
SKU: 161914
Price: 9.63 USD
Availability: InStock



Category DIN 41612 Connectors Brand HARTING Condition New

Specifications

Country of Origin	Switzerland
Brand	HARTING
Orientation	Straight
Current	2A
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Copper Alloy
Series	DIN 41612
Termination Type	Solder
Maximum Operating Temperature	125°C
Sub Type	C/2
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold over Nickel
Number of Contacts	64
Contact Gender	Male
Connector Gender	Male
Maximum Contact Resistance	20mΩ
Row Loading	A/B
ERNI 64 Way 2.54mm Pitch, 2 Row, Straight DIN 41612 Connector, PlugBrand	ERNI
HARTING Protection Cover, RS-K10D Series , For Use With 3 Module ConnectorBrand	HARTING

Key Features

The connector features 64 contacts for robust multi-pin connection.
Mount type is through hole suitable for PCB mounting with solder termination.
Designed to operate safely between -55°C and 125°C temperatures.
Gold over nickel plating ensures excellent contact resistance and corrosion protection.
Connector housing is made of durable polybutylene terephthalate material.
Compatibility with DIN 41612 series standards and type C/2 sub-type.
Current rating is 2A for reliable power transmission.
Straight orientation with male contact gender provides ease of installation.

Product Description

HARTING 09721646903 DIN 41612 64 Way Connector is a high-quality electrical component designed for use in industrial and electronic applications requiring reliable multi-pin connections. This connector features 64 contacts arranged in a 2-row male straight configuration with a 2.54 mm pitch, suitable for PCB mounting through hole soldering.

The connector is made with a copper alloy contact material plated with gold over nickel, providing excellent corrosion resistance and ensuring reliable electrical conductivity. Its housing is constructed from polybutylene terephthalate, known for its mechanical strength and thermal stability.

Operating temperature range from -55°C to 125°C makes it suitable for harsh environments in industrial and manufacturing settings. The connector supports a 2A current rating and complies with DIN 41612 series mechanical and electrical standards, specifically class C2 solder termination type and sub type C/2 row loading A/B.

This connector is typically used in backplane and rack mounting applications, providing robust and compact interconnection options for equipment, especially in telecommunications, computing, and automation industries. Its straight male design allows easy insertion into corresponding sockets or plugs, facilitating effective signal and power transmission.

64 contact points arranged in two rows for high-density connections. Through hole mount with solder terminations for secure PCB fixing. Gold plating over nickel contact ensures superior reliability and reduced oxidation.

Robust housing material withstands mechanical and thermal stresses. Wide operating temperature range enhances usage versatility. Current rating up to 2A suitable for control and signal circuits. Compatible with DIN 41612 standard connectors for system interoperability.

Male connector type with straight orientation for ease of installation.

This product is made in Switzerland and is classified as new. Its robust construction and standardized design make it an excellent choice for industrial electronics, automation systems, and hardware rack solutions. Explore more in the Connectors category or discover additional HARTING products on EnvMart.
