Siemens 125A Centred Tag Fuse NH00 690V AC HLS Blade Tag Type

Siemens 3NE8022-1 Centred Tag Fuse NH00 is a high-quality HLS fuse designed for electrical circuit protection at 125A and 690V AC. This fuse features a blade type tag with 6mm width, optimized for dependable installation in NH fuse bases or load switches. It is part of Siemens' 3NE Series of SITOR fuses, providing reliable semiconductor and overload protection.

The fuse has a high rupture capacity, enabling it to safely interrupt faults and short circuits, protecting cables, wires, and power rails. Its compact physical dimensions include an overall length of 79mm, height of 48mm, and width of 30mm, making it suitable for space-constrained electrical installations. The operating temperature spans from -20°C minimum to 60°C maximum, ensuring durability across varied working conditions.

This particular fuse is classified under operating class aR, offering partial-range semiconductor protection ideal for industrial and commercial electrical systems. Manufactured in Greece, the 3NE8022-1 fuse complies with IEC 60269-2 standards, although no explicit approvals are listed.

High rupture capacity for enhanced safety. Blade tag type with 6mm width for strong connection. Wide operating temperature range from -20°C to 60°C. Compact dimensions suitable for NH00 size fuse holders. Application category aR for semiconductor protection.

Part of Siemens 3NE Series SITOR fuses. Designed for overload and short circuit protection of electrical installations.

This fuse is suitable for electrical, industrial, and automation applications requiring reliable circuit protection. Explore the Siemens fuses range on EnvMart for compatible components and fuse accessories.
