SMC 2 Finger Double Acting Action Pneumatic Gripper, Angle Gripping Type, Bore Diameter 10mm, Max Operating MHC2-10D

Free Delivery in India | Lowest Global Shipping Charges

SMC 2 Finger Double Acting Action Pneumatic Gripper, Angle Gripping Type, Bore Diameter 10mm, Max Operating MHC2-10D



Category Pneumatic Gripper Brand SMC Condition New

Specifications

Country of Origin	India
Brand	SMC
Maximum Operating Pressure	0.6 Mpa
Height	23mm
Length	52.4mm
Model	MHC2-10D
Gross Weight	39g
Width	16.4mm
Series	MHC2
Maximum Operating Temperature	60°C
Port Size	M3 x 0.5
Minimum Operating Temperature	-10°C
Bore Diameter	10mm
Open Width	10mm
Action Type	Double Acting
Standards/Approvals	RoHS
Number of Fingers	2
Gripping Type	Angle
Gripping Force - Internal	0.1Nm
Closed Width	10mm

Key Features

Double acting pneumatic action ensures reliable gripping.
Angle gripping type suitable for angular object handling.
Maximum operating pressure of 0.6 Mpa for efficient operation.
Operating temperature range from -10°C to 60°C.
Gripping forces of 0.1Nm internally and externally.
Maximum operating frequency up to 180 cycles per minute.
Repeatability of closing position ±0.01mm for high precision.
Lubrication free design reduces maintenance needs.

Product Description

SMC MHC2-10D is a 2 finger double acting pneumatic gripper designed for precise and reliable gripping in industrial automation applications. The gripper features a 10mm bore diameter and uses an angle gripping type ideal for angular handling tasks.

The device operates efficiently at a maximum pressure of 0.6 Mpa and supports a maximum operating frequency of 180 cycles per minute, allowing fast and consistent performance in manufacturing lines, assembly, and material handling.

This pneumatic gripper has compact dimensions with a length of 52.4mm, height of 23mm, and width of 16.4mm, making it suitable for installations with limited space. It operates within a temperature range of -10°C to 60°C, ensuring durability in various industrial environments.

The gripping forces of 0.1Nm internally and externally provide sufficient holding power for small to medium components. The device offers high repeatability with a closing position accuracy of ±0.01mm, guaranteeing precision in repeated operations.

Designed for ease of use, the MHC2-10D requires no lubrication, reducing maintenance requirements and downtime. Typical applications include automated assembly, robotic gripping, material transfer, and packaging.

Double acting pneumatic gripping action for reliable grip control. Angle gripping type for effective angular gripping applications. High repeatability ensures consistent operation accuracy. Compact and lightweight design for versatile mounting.

Operating temperature range suited for industrial environments. Lubrication free design minimizes upkeep. Compatible with pneumatic control systems using M3 x 0.5 ports.

This pneumatic gripper is RoHS compliant and engineered for demanding industrial automation tasks. Broaden your pneumatic tooling capabilities with the high-performance SMC MHC2-10D gripper.

Explore more in the Pneumatic Gripper category at EnvMart for reliable pneumatic component solutions.
