Festo 5/2 Way Monostable Solenoid Valve G 1/8 Port Size Aluminium Alloy Body 24V DC 1W VUVG-L14-M52-MT-G18-1H2L-W1
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 24V dc |
| Brand | Festo |
| Body Material | Aluminium Alloy |
| Maximum Operating Pressure | 8 bar |
| Model | VUVG-L14-M52-MT-G18-1H2L-W1 |
| Width | 14mm |
| Mount Type | In-Line |
| Series | VUVG |
| Number Of Ports | 5 |
| Maximum Operating Temperature | 60°C |
| Number of Positions | 2 |
| Port Size | 1/8 in |
| Seal Material | Nitrile Rubber (NBR) |
| Minimum Operating Temperature | -5°C |
| Actuation Type | Solenoid |
| Protection | IP 40/IP 65 |
| Maximum Flow Rate | 780L/min |
| Standards/Approvals | CSA, cULus, RoHS |
| Connection Thread Standard | G 1/8 |
| Minimum Pilot Pressure | 3bar |
| Valve Function | 5/2 |
| Electrical Connection Type | Electrical Connection Plate |
| Solenoid Type | Single |
| Port Gender | Female |
| Solenoid Power Consumption | 1W |
Key Features
- Compact design suitable for installations where space, weight, and flow rate are critical.
- Operates with a voltage of 24V DC and solenoid power consumption of 1W.
- Features a piston spool with sealing cartridge design ensuring durability and efficiency.
- Valve function is 5/2 way monostable with internal pilot air supply and female G 1/8 thread connection.
- Maximum operating pressure of 8 bar and maximum flow rate of 780 L/min.
- Operating temperature ranges from -5°C to 60°C, making it suitable for varied industrial environments.
- Constructed with nitrile rubber (NBR) seals for reliable sealing performance.
- Protection rated at IP 40/IP 65 for resistance against environmental factors.
Product Description
Festo VUVG-L14-M52-MT-G18-1H2L-W1 pneumatic solenoid valve is a 5/2 way monostable valve constructed with an aluminium alloy body and designed for efficient control of pneumatic systems. It operates on 24V DC voltage with a low power consumption of 1W, making it energy efficient.
This valve uses a piston spool with sealing cartridge principle to provide reliable operation and longevity. The valve features a G 1/8 female threaded connection and internal pilot air supply ensuring ease of integration and installation in pneumatic circuits without the need for additional pneumatic linking.
The valve offers a maximum operating pressure of 8 bar and a maximum flow rate of 780 L/min, suitable for high flow rate applications requiring compact and lightweight components. It supports a temperature operating range from -5°C to 60°C, allowing use in various industrial settings.
Reliable sealing is guaranteed with nitrile rubber (NBR) seals, and protection ratings of IP 40/IP 65 provide environmental resistance. The valve is also certified with CSA, cULus, and RoHS standards, ensuring safety and environmental compliance for industrial use.
Installation and maintenance are simplified with features such as quick push connectors and an integrated 360° LED display for easier troubleshooting and status monitoring. These valves are suitable for use in laboratory, manufacturing, pneumatic automation systems, and other industrial control applications where space, weight, and flow performance are key considerations.
Compact design for space-saving installations. Energy efficient solenoid operation at 24V DC and 1W power consumption. Durable piston spool with sealing cartridge construction. Internal pilot air supply for simplified pneumatic connection.
High flow rate up to 780 L/min at 8 bar pressure. Wide operating temperature from -5°C to 60°C. Durable NBR seal material and aluminium alloy body. Protection class IP 40/IP 65 enhances reliability in harsh environments.
Certified compliant with CSA, cULus, and RoHS standards. LED status display allows fast troubleshooting and system checks. Explore a wide selection of Pneumatic Solenoid Valves and related automation components at EnvMart for efficient and reliable industrial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 8 bar.
It has a maximum flow rate of 780 L/min.
This unit operates at a voltage of 24V DC.
The body is made from aluminium alloy, and it features nitrile rubber (NBR) seals for reliable sealing performance.
The width of this model is 14mm.
It can operate within a temperature range of -5°C to 60°C.
This valve is actuated by a solenoid.
It features a G 1/8 female threaded connection for easy integration into pneumatic circuits.
It has a protection rating of IP 40/IP 65, providing resistance against environmental factors.
It is certified with CSA, cULus, and RoHS standards, ensuring safety and environmental compliance.
This model functions as a 5/2 way monostable valve.
The solenoid power consumption of this unit is 1W.
