Inventronics Enclosed LED Driver 24.2V 250W 10.33A Constant Voltage IP66 IP67 Dimmable OPTOTRONIC Series 4052899545908

Free Delivery in India | Lowest Global Shipping Charges

Inventronics Enclosed LED Driver 24.2V 250W 10.33A Constant Voltage IP66 IP67 Dimmable OPTOTRONIC Series 4052899545908

Name: Inventronics Enclosed LED Driver 24.2V 250W 10.33A Constant Voltage IP66 IP67 Dimmable OPTOTRONIC Series 4052899545908
Brand: Inventronics
SKU: 154498



Category LED Drivers Brand Inventronics Condition New

Specifications

Country of Origin	China
Brand	Inventronics
IP Rating	IP66, IP67
Mount Type	Screw
Series	OPTOTRONIC
Configuration	Enclosed
Sub Type	LED Driver
Operating Modes	Constant Voltage
Number of outputs	1
Terminal type	Wire
Maximum Output Power	250W
Input Voltage	220, 240V
Output Voltage	24.2V
Power Dissipation	20W
Standards/Approvals	RCM, ENEC, EN, EAC, CE, CCC
Dimming Operation	1/10 V
Primary Type	DC-DC, AC
Driver Current	10.33A
LED Voltage	240V

Key Features

Enclosed design with IP66 and IP67 ratings for robust indoor and outdoor use.
Supports 1/10 V dimming operation with fully isolated interface.
Input voltage range from 198VAC to 264VAC compatible with 220V and 240V supply.
Features short circuit, overload, and over-temperature protection for reliability.
Power dissipation of 20W ensuring efficient operation.
Complies with multiple international standards and approvals including RCM, ENEC, CE, and CCC.
Designed in the OPTOTRONIC series with DC-DC and AC primary types.
Ideal for facades, signage, public squares, cruise ships, and both indoor and outdoor installations.

Product Description

Inventronics 4052899545908 is an enclosed LED driver engineered to deliver a stable 24.2V constant voltage output with a maximum power rating of 250W and a driver current of 10.33A. Designed for demanding lighting applications, it supports dimming via a fully isolated 1V to 10V interface ensuring precise light control.

This LED driver operates efficiently within an input voltage range of 198VAC to 264VAC, compatible with typical 220V and 240V supply voltages. It is constructed with a robust enclosure rated IP66 and IP67, making it suitable for both indoor and outdoor environments including facades, public squares, cruise ships, and signage installations.

The product features comprehensive protection mechanisms including electronic reversible short circuit, overload, and over-temperature protection to enhance operational reliability and longevity. Power dissipation is maintained at 20W to optimize efficiency.

It complies with stringent international standards such as RCM, ENEC, EN, EAC, CE, and CCC certifications ensuring high quality and safety. This device belongs to the OPTOTRONIC series by Inventronics and integrates both DC-DC and AC primary power configurations.

The LED driver is especially designed for harsh environmental conditions, capable of installation in very cold and hot climates, with a storage temperature range between -40°C and 85°C and an expected service life of up to 50,000 hours.

Enclosed IP66 and IP67 rated robust enclosure for environmental protection. High reliability with short circuit, overload, and temperature protections. Exact 24.2V constant voltage output for LED applications. Supports 1/10 V dimming operation for flexible lighting control.

Certified to multiple global standards ensuring safety and performance. Designed for stable operation in cold and hot temperatures. Long lifetime of up to 50,000 hours for durable use. Suitable for indoor and outdoor LED lighting applications such as facades, signage, and public areas.

Choose Inventronics OPTOTRONIC 4052899545908 LED Driver for efficient, reliable, and high-performance LED lighting control solutions. Explore broader selections of LED Drivers and related electronic components with EnvMart for your industrial, commercial, and specialized lighting needs.
