Weidmüller BVZ Series Pluggable Terminal Block 6-Contact 7.62 mm Pitch 1 Row 1kV 40A Screw Connection Female 1929970000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 1kV |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 40A |
| Length | 44.1mm |
| Depth | 23.1mm |
| Width | 41.2mm |
| Housing Material | Polyamide Fibreglass, Copper Alloy |
| Series | BVZ |
| Number of Rows | 1 |
| Pitch | 7.62mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 6 |
| Connector Gender | Female |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 10mm² |
| Minimum Wire Size AWG | 24AWG |
| Maximum Wire Size AWG | 8AWG |
| Wire Connection Method | Screw |
Key Features
- Features a female connector design with screw wire connection method.
- Compatible with wire sizes from 0.2 mm² up to 10 mm² or AWG 24 to AWG 8.
- Built with durable polyamide fiberglass and copper alloy housing for longevity.
- Right angle orientation ensures efficient space utilization in assemblies.
- Rated for voltage up to 1 kV with compliance to RoHS standards.
- Designed in Germany to ensure high manufacturing standards and reliability.
Product Description
Weidmüller 1929970000 BVZ Series Pluggable Terminal Block is engineered for industrial and electrical applications requiring safe and reliable connection with a 6-contact configuration. Featuring a 7.62 mm pitch and single row, this terminal block supports current load of up to 40A and voltage rating of 1 kV.
The female plug is arranged in a 180° outlet direction, using a clamping yoke screw connection ideal for TNC (S) systems. The mating profile ensures touch safety greater than 3 mm, providing operational reliability even under thermal derating conditions up to 125 °C. The unique coding capability prevents incorrect mating and enhances system integrity.
Constructed with polyamide fiberglass and copper alloy housing, the block offers durability and corrosion resistance necessary in industrial environments. It supports a wire size range from 0.2 mm² to 10 mm² (24 AWG to 8 AWG), facilitating versatile connectivity. The right angle orientation is designed for efficient panel mounting and wiring layout.
This product complies with RoHS standards, ensuring environmental compliance and safety. Dimensions are 44.1 mm length, 41.2 mm width, and 23.1 mm depth, making it suitable for compact electrical assemblies. Country of Origin is Germany, signifying premium manufacturing quality.
Features a female connector with screw connection for secure wire attachment. Supports current of 40A and voltage up to 1 kV for high power applications. Polyamide fiberglass and copper alloy construction ensures durability.
Right angle orientation for optimized installation space. Compliant with RoHS environmental standards. Compact dimensions allow flexible system integration. Unique mating profile prevents incorrect connections increasing reliability.
This terminal block is widely used in electrical panels, industrial automation, power distribution, and control systems. Its robust design and safety features make it ideal for manufacturing, electronics, and high-performance industrial applications.
Explore more Weidmüller Pluggable Terminal Blocks and related components at EnvMart for reliable industrial electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It is rated for a voltage of up to 1 kV, making it suitable for high power applications.
This terminal block can support a maximum current load of 40A.
It supports wire sizes from 0.2 mm² up to 10 mm², or AWG 24 to AWG 8.
The housing is made of polyamide fiberglass and copper alloy, providing durability and corrosion resistance.
The pitch of this model is 7.62 mm, designed for efficient connectivity in compact spaces.
It features a 6-contact configuration, allowing for multiple connections in a single unit.
It has a right angle orientation, which optimizes installation space in electrical assemblies.
Yes, it complies with RoHS standards, ensuring environmental compliance and safety.
The dimensions are 44.1 mm in length, 41.2 mm in width, and 23.1 mm in depth.
It utilizes a screw connection method for secure wire attachment.
It is designed and manufactured in Germany, ensuring high manufacturing standards.
It is widely used in electrical panels, industrial automation, power distribution, and control systems.
