EA Elektro-Automatik Digital Bench Power Supply 1-Output 0 V to 500 V 1.5 kW 10 A Max EA-PS 9500-10 T

Free Delivery in India | Lowest Global Shipping Charges

EA Elektro-Automatik Digital Bench Power Supply 1-Output 0 V to 500 V 1.5 kW 10 A Max EA-PS 9500-10 T

Name: EA Elektro-Automatik Digital Bench Power Supply 1-Output 0 V to 500 V 1.5 kW 10 A Max EA-PS 9500-10 T
Brand: EA Elektro-Automatik
SKU: 146134



Category Bench Power Supplies Brand EA Elektro-Automatik Condition New

Specifications

Country of Origin	Germany
Brand	EA Elektro-Automatik
Power	1.5kW
Height	239mm
Model	EA-PS 9500-10 T
Depth	335mm
Width	92mm
Output type	Digital
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
Plug Type	USB
Number of outputs	1
Maximum Output Current	10A
Standards/Approvals	RoHS
Maximum Output Voltage	500V
Maximum Supply Voltage	264V ac
Minimum Supply Voltage	90V
Digital/Analogue	Digital
Supported Number of Displays	1
Minimum Output Voltage	0V
Minimum Output Current	0A
Standard on-board USB Interface. Optional	3-way Interface analogue 0-5V/0-10V, USB, Ethernet/LAN (all galvanically isolated, easy plug and play retrofit)
Auto-ranging Output	Compared to power systems with conventional (rectangular) output characteristic, the auto-ranging feature allows to power a much larger number of devices (EUTs) with different nominal voltages

Key Features

Auto-ranging output allows powering a wide range of devices with different nominal voltages.
High electro-magnetic immunity ensures reliable operation in industrial environments.
Features a color TFT touch screen display for intuitive operation and clear read-back values.
Standard USB interface with optional galvanically isolated analogue and Ethernet/LAN interfaces.
High programming accuracy with 16-bit resolution and 0.1% nominal voltage accuracy.
Fast microprocessor control enables rapid programming-reaction times up to ten times faster than predecessors.
Safety complies with IEC/EN 61010 standards, ensuring user protection and device reliability.
Compact tower design saves bench space while providing flexible user profiles and controls.

Product Description

EA Elektro-Automatik EA-PS 9500-10 T is a high-performance digital bench power supply designed for industrial and laboratory applications. It features one output channel delivering variable voltage from 0 V to 500 V, with a maximum current capacity of 10 A and power rating of 1.5 kW. This adjustable, programmable unit supports precise power delivery with a 16-bit digital resolution and 0.1% voltage accuracy, suitable for sensitive electronic testing and measurement tasks.

The device incorporates an auto-ranging output characteristic, significantly expanding compatibility with diverse devices under test (EUTs) across wide voltage ranges. The bench power supply’s highly isolated structure offers superior resistance to electromagnetic interference, providing robust performance in demanding industrial environments. The compact tower form factor is space-saving without compromising functionality.

Operation is facilitated via a vibrant color TFT touch screen with 64,000 colors, presenting an intuitive interface for setting and monitoring output parameters. The unit includes a high-speed microprocessor controller capable of up to ten times faster programming reaction time than previous models, enhancing operational responsiveness and precision.

Connectivity options include a standard USB interface with optional analogue (0-5V/0-10V), USB, and Ethernet/LAN interface modules, all galvanically isolated for safety and ease of integration. The output capacitance discharges rapidly in accordance with IEC 1010, ensuring user safety by reducing residual voltage to below 10 seconds in no-load conditions.

Certified RoHS compliant, this power supply meets stringent international safety standards including IEC/EN 61010. The product is manufactured in Germany and designed for use in electrical, electronic testing, research and development laboratories, quality control, and manufacturing settings. Its reliability and versatility make it well suited for industrial, commercial, and educational applications.

Auto-ranging output supports a wide range of test devices. Robust EMI compliance for industrial environments. High resolution and fast programming for precision testing. Multiple galvanically isolated interfaces for flexible connectivity.

Compact tower design maximizes bench space. High safety standard adherence for user protection. Manufactured in Germany offering quality assurance. Ideal for laboratory, industrial, and manufacturing use cases. Explore more in the Bench Power Supplies category on EnvMart for advanced testing and measurement instruments by EA Elektro-Automatik and other leading manufacturers.
