Festo Pneumatic Rotary Actuator Double Acting Action 8 Bar Maximum Operating Pressure 12mm Bore DRVS-12-90-P

Free Delivery in India | Lowest Global Shipping Charges

Festo Pneumatic Rotary Actuator Double Acting Action 8 Bar Maximum Operating Pressure 12mm Bore DRVS-12-90-P

Name: Festo Pneumatic Rotary Actuator Double Acting Action 8 Bar Maximum Operating Pressure 12mm Bore DRVS-12-90-P
Brand: FESTO
SKU: 145425
Price: 192.82 USD
Availability: InStock



Category Pneumatic Rotary Actuator Brand FESTO Condition New

Specifications

Country of Origin	Germany
Brand	Festo
Maximum Operating Pressure	8 bar
Model	DRVS-12-90-P
Gross Weight	154g
Series	DRVS
Maximum Operating Temperature	60°C
Sub Type	Rotary Vane
Minimum Operating Temperature	0°C
Bore Diameter	12mm
Action Type	Double Acting
Standards/Approvals	RoHS
Better World Claim	Repairable by the End User
Cushioning Type	Elastic
Port Thread Size	M5
Maximum Axial Force	120N
Maximum Radial Force	25N
Maximum Torque Rating	1Nm

Key Features

Designed for double acting pneumatic operation for enhanced control.
Has elastic cushioning for smooth and controlled motion.
Lightweight at 154 grams for easy installation and integration.
Operates within a temperature range of 0°C to 60°C.
Features a swivel angle from 0 to 90 degrees suitable for versatile movement.
Maximum torque output of 1 Nm provides effective rotary force.
Suitable for industrial automation requiring precise rotary actuation.
Constructed to withstand axial force up to 120 N and radial force up to 25 N.

Product Description

Festo DRVS-12-90-P pneumatic rotary actuator is a high-performance automation component designed for industrial applications requiring precise and efficient rotary motion control. This actuator features a 12mm bore diameter and operates with a maximum pressure of 8 bar using double acting action, allowing bidirectional control of rotary movement over a 0 to 90-degree swivel angle.

Engineered with elastic cushioning and flexible cushioning rings, it provides smooth and controlled actuation, minimizing mechanical shocks. Its lightweight construction at 154 grams facilitates easy mounting and integration into compact systems. The device withstands operating temperatures from 0 to 60 degrees Celsius, making it suitable for various environmental conditions.

This rotary vane type actuator delivers a maximum torque of 1 Nm, with the capacity to handle axial forces up to 120 N and radial forces up to 25 N, ensuring robust performance in demanding industrial settings. The M5 port thread size supports compatible pneumatic fittings for versatile installation.

Manufactured in Germany to stringent quality standards, including RoHS compliance, this actuator is repairable by the end user, supporting sustainable maintenance practices. Double acting pneumatic operation for precise rotary control.

Elastic cushioning ensures smooth motion. Compact and lightweight design at 154 grams. Swivel angle of 0 to 90 degrees for versatile positioning. Maximum torque rating of 1 Nm for effective actuation. Operates within 0°C to 60°C temperature range.

Maximum axial force of 120 N and radial force of 25 N. M5 port thread size for easy pneumatic connection. RoHS compliant and manufactured in Germany. Repairable by the end user for sustainable use.

This Pneumatic Rotary Actuator is ideal for industrial, manufacturing automation, fluid power control systems, and other industrial machinery requiring reliable rotary motion actuation. Explore EnvMart for more Festo pneumatic components and complementary industrial automation products.
