Relpol PCB Power Relay 9V DC Coil 5A Switching Current SPDT RM40-2011-85-1009

Free Delivery in India | Lowest Global Shipping Charges

Relpol PCB Power Relay 9V DC Coil 5A Switching Current SPDT RM40-2011-85-1009

Name: Relpol PCB Power Relay 9V DC Coil 5A Switching Current SPDT RM40-2011-85-1009
Brand: Relpol
SKU: 144141
Price: 16.99 USD
Availability: InStock



Category Power Relays Brand Relpol Condition New

Specifications

Country of Origin	Poland
Brand	Relpol
Height	10.5mm
Length	20mm
Model	RM40-2011-85-1009
Width	10mm
Mount Type	PCB
Contact Material	Silver Alloy
Series	RM40
Maximum Operating Temperature	85°C
Contact Configuration	SPDT
Minimum Operating Temperature	-40°C
Switching Current	5A
Terminal type	PCB Pin
Contact Resistance	100mΩ
Standards/Approvals	RoHS, VDE
Coil Resistance	405Ω
Coil Voltage	9V dc
Switching DC Voltage	48V dc
Switching AC Voltage	380V ac
Coil Power	200mW

Key Features

Equipped with a 9V DC coil for reliable operation.
Supports a switching current of up to 5A.
Contact configuration is Single Pole Double Throw (SPDT) for versatile switching.
Designed for PCB mounting with PCB pin terminals.
Operating temperature range from -40°C to 85°C.
Coil power consumption is 200mW for efficient energy use.
Switching voltage capacity up to 48V DC and 380V AC.
Contact material is high-quality silver alloy ensuring durability.

Product Description

Relpol RM40-2011-85-1009 PCB Power Relay is engineered for reliable general-purpose switching applications in industrial, automotive, and electronic equipment. Featuring a 9V DC coil and a 5A switching capability, this relay is ideal for PCB mounting in compact circuits.

This relay employs a Single Pole Double Throw (SPDT) contact configuration and high-quality silver alloy contacts to ensure durable and efficient switching with low contact resistance of 100mΩ. It supports switching voltages of up to 48V DC and 380V AC, making it suitable for various electrical environments.

The relay dimensions are 20mm length, 10mm width, and 10.5mm height, designed for easy integration on printed circuit boards with PCB pin terminals. The operating temperature range from -40°C to 85°C and coil power consumption of 200mW underscore its robustness and energy efficiency.

Compliance with RoHS and VDE standards guarantees this relay meets strict regulatory requirements for safety and environmental protection. The relay is manufactured in Poland, assuring high manufacturing quality.

Equipped with a 9V DC coil for reliable operation. 5A switching current capacity supports high load requirements. SPDT contact configuration allows versatile electrical switching. PCB mounting with secure PCB pin terminals.

Compact form factor measuring 20mm × 10mm × 10.5mm. Wide temperature operating range from -40°C to 85°C for diverse environments. Efficient coil power of 200mW. Supports DC switching voltage up to 48V and AC switching voltage up to 380V.

Silver alloy contacts enhance durability and reduce contact resistance. Certified to RoHS and VDE standards.

This Relpol PCB Power Relay RM40-2011-85-1009 is well-suited for applications in industrial automation, electronic circuit control, HVAC systems, automotive electronics, and manufacturing equipment. Its precise engineering and certifications ensure reliable performance under demanding conditions.
