SICK Through Beam Photoelectric Fork Sensor, Push Pull Output, IP65, Infrared Light Source, 30V DC, 20mA WFS3-40B41CA71
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | SICK |
| Response time | 46μs |
| Light Source | Infrared |
| Model | WFS3-40B41CA71 |
| IP Rating | IP65 |
| Mount Type | Panel Mount |
| Housing Material | Polyamide |
| Output type | Push Pull |
| Series | WFS |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -20°C |
| Maximum Current | 20mA |
| DetectIon Type | Through Beam |
| Terminal type | 4-Pin M8 |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | CE, EN 60068-2-27 |
| Sensor Style | Fork |
Key Features
- The sensor features a fork style with through beam detection for precise object sensing.
- Push pull output type ensures versatile switching capability compatible with various control systems.
- The device operates at a maximum DC voltage of 30V and maximum current of 20mA.
- Robust polyamide housing provides IP65 ingress protection suited for industrial environments.
- Equipped with an infrared light source, the sensor performs reliably across temperatures from -20°C to 60°C.
- Quick and easy panel mounting simplifies installation in automation setups.
- Response time is fast at 46 microseconds, supporting high-speed detection tasks.
- Designed for operation without hazardous area certification, enhancing safety in standard environments.
Product Description
SICK WFS3-40B41CA71 through beam photoelectric fork sensor combines precision object detection with a rugged and versatile design for industrial automation applications.
This fork sensor integrates the sender and receiver into a single polyamide housing, providing reliable detection of objects with a detection range greater than 2 mm. It employs an infrared light source and push pull output type to ensure fast and adaptable operation suitable for complex control systems.
The sensor is rated IP65, ensuring resistance to dust and low pressure water jets, making it ideal for use in manufacturing, assembly lines, packaging, and quality control environments where environmental conditions may vary.
Featuring a quick panel mount design and a response time of just 46 microseconds, the sensor supports rapid detection needs with minimal installation complexity.
The device is designed for standard industrial environments without hazardous area certification requirements, conforming to CE and EN 60068-2-27 standards for robustness and reliability.
Temperature operating range of -20°C to 60°C allows deployment in varied industrial climates, while its single-lens system ensures detection through minimal openings. Manufactured in Germany, the WFS3-40B41CA71 ensures high quality and precision aligning with global automation standards.
The sensor features a fork style with through beam detection for precise object sensing. Push pull output type ensures versatile switching capability compatible with various control systems. The device operates at a maximum DC voltage of 30V and maximum current of 20mA.
Robust polyamide housing provides IP65 ingress protection suited for industrial environments. Equipped with an infrared light source, the sensor performs reliably across temperatures from -20°C to 60°C. Quick and easy panel mounting simplifies installation in automation setups.
Response time is fast at 46 microseconds, supporting high-speed detection tasks. Designed for operation without hazardous area certification, enhancing safety in standard environments. Complies with CE and EN 60068-2-27 standards ensuring quality and durability.
Manufactured in Germany, assuring premium build quality. Explore SICK Photoelectric Sensors and automation control gear on EnvMart for reliable industrial sensor solutions and enhanced automation system performance.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The response time of this sensor is 46 microseconds, allowing for fast detection of objects.
The maximum operating voltage for this model is 30V DC.
This sensor features a push pull output type, which provides versatile switching capabilities compatible with various control systems.
The WFS3-40B41CA71 uses through beam detection for precise object sensing.
It operates reliably within a temperature range of -20°C to 60°C.
The sensor has an IP65 rating, providing protection against dust and low pressure water jets.
The housing of this model is made from polyamide, which contributes to its robustness in industrial environments.
This sensor features a quick panel mount design, simplifying installation in automation setups.
It is equipped with an infrared light source for object detection.
This sensor complies with CE and EN 60068-2-27 standards, ensuring quality and reliability.
The sensor features a 4-pin M8 terminal type for connections.
This model is manufactured in Germany, assuring a high standard of quality.
