Eaton C22 Series Push Button Switch Panel Mount 22 mm Cutout Red SPST IP67 IP69K 181043 C22-D-R-K01-P5

Eaton 181043 C22-D-R-K01-P5 Push Button Switch is a panel mount switch designed with a 22 mm cutout and red round push button. It features a momentary push button actuation with SPST contact configuration suitable for various industrial and electrical control applications.

This robust switch offers an IP67 and IP69K ingress protection rating, making it resistant to dust, water, and high-pressure washdowns, ideal for harsh and wet environments in industrial, manufacturing, and automation settings.

The switch operates reliably within a temperature range of -25°C to 70°C and is built with a corrosion-resistant silver-colored nylon bezel and plastic body that provides durability and longevity withstanding up to 5 million mechanical cycles.

It is mounted using a notched hole with an anti-rotation tab and central nut mounting method, facilitating secure and accurate installation on control panels. The single-pole single-throw (SPST) contact configuration and screw terminal type offer simple yet effective control and connection options for electrical circuits.

The push button diameter is 29.7 mm, constructed of high-quality plastic material for ergonomic and reliable usage. This switch meets multiple international certifications, including CE marking, CSA, UL, VDE, and IEC standards, ensuring compliance and quality.

The switch features a 22 mm cutout for panel mounting and a red round plastic push button. It has a single-pole single-throw (SPST) contact configuration for basic on/off control. The switch is rated for IP67 and IP69K, ensuring protection against dust and water ingress.

It operates in temperatures from -25°C to 70°C, suitable for harsh environments. The mounting system includes a notched hole with anti-rotation tab and central nut. Construction is heavy-duty corrosion resistant with a silver colored nylon bezel and plastic body.

The push button diameter measures 29.7 mm and the material is durable plastic. The switch is designed for up to 5 million mechanical operations, ensuring long service life. Terminal connections are screw type for secure electrical contacts.

Certifications include NKCR, CE marking, CSA, IEC/EN0947-5-1, VDE 0660, CE, and UL standards.

This Eaton C22 Series Push Button Switch provides reliable and durable operation in industrial automation, electrical panels, machinery controls, and other commercial applications requiring robust and high-performance push button switching.
