APEM Raised Rotary Coded DIP Switch Through Hole NDS-06-V

APEM NDS-06-V Raised Rotary Coded DIP Switch is an industrial-grade Rotary Coded DIP Switch designed for through-hole mounting on printed circuit boards (PCBs). This switch features a raised actuator type providing tactile engagement for precise operation. It employs a single-pole single-throw (SPST) configuration, making it suitable for a variety of electronic control and switching applications.

The switch supports a switching rating of 25mA at 24Vdc and a non-switching rating of 100mA at 50Vdc, capable of handling low-current signalling requirements found in telecommunication, computing, test instrumentation, and security equipment. The operational force of 10N maximum ensures firm actuation with a stroke length of 2mm, providing reliability and durability under repeated use.

Its through-hole mount type allows for secure soldering onto PCB substrates, ensuring electrical and mechanical stability in circuit designs. Single-pole single-throw (SPST) switch type. Raised actuator design for tactile feedback.

Switching rating: 25mA at 24Vdc; non-switching rating: 100mA at 50Vdc. Operation force up to 10N and 2mm actuator stroke. Manufactured in China with consistent industrial standards.

Applications encompass telecom systems, computer hardware, instrumentation panels, and security devices requiring reliable low-current switching components. This product is suitable for engineers and designers seeking dependable rotary DIP switches for their electronic projects.

EnvMart offers this high-quality APEM switch ensuring robust performance in demanding industrial and electronic applications.
