Ruland Aluminium Set Screw Style Flexible Coupler 12.7 mm OD 5 mm Bore 5.6 mm Length MOST13-5-A

Free Delivery in India | Lowest Global Shipping Charges

Ruland Aluminium Set Screw Style Flexible Coupler 12.7 mm OD 5 mm Bore 5.6 mm Length MOST13-5-A

Name: Ruland Aluminium Set Screw Style Flexible Coupler 12.7 mm OD 5 mm Bore 5.6 mm Length MOST13-5-A
Brand: Ruland
SKU: 129488
Price: 61.8 USD
Availability: InStock



Category Mechanical Power Transmission Couplings Brand Ruland Condition New

Specifications

Country of Origin	United States
Brand	Ruland
Material	Aluminium
Model	MOST13-5-A
Maximum Speed	4500rpm
Outside diameter	12.7mm
Bore Diameter	5mm
Bore Type	Finished with No Keyway
Standards/Approvals	RoHS, REACH
Misalignment - Angular	0.5°
Misalignment - Parallel	0.1mm
Misalignment - Axial	0.1mm
Hub Length	5.6mm
Securing	13mm and 19mm anodised aluminium hubs are secured to the shafts with one set screw on each end. 33mm, 35mm and 41mm hubs have 2 set screws set 90° apart

Key Features

Constructed of durable aluminium for light industrial applications.
Set screw style coupling designed without keyway bore for secure shaft connection.
Accommodates angular misalignment up to 0.5 degrees and parallel misalignment up to 0.1 mm.
Hub length of 5.6 mm ensures compact assembly installation.
RoHS and REACH compliant for environmental safety.
Manufactured in the United States with high quality standards.
Suitable for motion control, stepper, and servo motor applications.
Centre torque disc protects machinery from torque overload by breaking cleanly.

Product Description

Ruland MOST13-5-A aluminium set screw style flexible coupler features a 12.7 mm outside diameter, 5 mm bore diameter, and 5.6 mm hub length designed for reliable coupling of shafts in light industrial and motion control applications. It is engineered to accommodate small angular, parallel, and axial misalignments making it suitable for precise mechanical power transmission tasks.

This set screw style Oldham coupling includes two anodised aluminium hubs and a replaceable centre torque disc made of acetal or nylon, providing torsional protection to connected equipment by acting as torque limiters. The unique three-piece design ensures robust performance while protecting machinery from overloads with easily replaceable discs.

With a rated maximum rotational speed of 4500 rpm, it is ideal for use with servo and stepper motors and other motion control systems, particularly where electrical isolation and minimal inertia are critical. The coupler's construction complies with RoHS and REACH directives, emphasizing its environmental compliance and safety.

The hubs are secured to the shafts via one set screw on the smaller diameters (13 mm and 19 mm hubs). Larger hub sizes use two set screws positioned 90° apart to ensure a secure fit.

Durable aluminium construction for lightweight strength. Flexible coupling allowing up to 0.5° angular misalignment and 0.1 mm parallel and axial misalignment. Set screw style with no keyway bore for ease of assembly. Compliant with RoHS and REACH standards.

Manufactured in the United States ensuring quality and reliability. Protects connected machinery through torque limiting centre discs. Ideal for light industrial, laboratory, HVAC, and industrial automation applications.

Set contains two hubs and one centre torque disc required per assembly; components sold separately. This Ruland flexible coupling is a critical component used in Industrial Tools & Equipment, Mechanical Machinery & Spares for Mechanical Power Transmission Couplings.
