HARTING 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock Female 09664526613

Free Delivery in India | Lowest Global Shipping Charges

HARTING 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock Female 09664526613

Name: HARTING 37 Way Right Angle 2.76 mm Pitch Through Hole D-Sub Connector with 4 to 40 UNC Screw Lock Female 09664526613
Brand: HARTING
SKU: 126871



Category D-Sub Connector Brand HARTING Condition New

Specifications

Country of Origin	Switzerland
Brand	HARTING
Orientation	Right Angle
Current	7.5A
Mount Type	Through Hole
Housing Material	Steel
Contact Material	Copper Alloy
Mounting Hardware	4 to 40 UNC Screw Lock
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Pitch	2.76mm
Contact Plating	Gold
Number of Contacts	37
Contact Gender	Female
Connector Gender	Female
Connector Type D	D-Sub

Key Features

Designed with 37 female contacts for reliable connectivity.
Constructed with a steel housing for enhanced durability.
Features gold-plated copper alloy contacts for superior conductivity and corrosion resistance.
Operates efficiently between -55°C to 125°C temperature range.
Equipped with 4 to 40 UNC screw lock mounting hardware ensuring stable connections.
Solder termination type suitable for secure soldered connections.
Complies with IEC 60 807 standards for industrial use.
Ideal for cable-to-board applications in communication and data interfacing.

Product Description

HARTING 09664526613 is a 37 Way Right Angle D-Sub Connector featuring a 2.76 mm pitch and through-hole mounting. This connector is equipped with female gender contacts and uses a 4 to 40 UNC screw lock for secure fastening. Manufactured with a robust steel housing and gold-plated copper alloy contacts, it ensures reliable electrical connections in demanding industrial environments.

This connector operates effectively within a temperature range of -55°C to 125°C, making it suitable for a variety of industrial, electronic, and communication applications. Designed according to IEC 60 807 standards, it offers excellent durability and mating cycle performance for cable-to-board and data interfacing needs.

The solder termination type simplifies integration on printed circuit boards. This product is ideal for use in industrial manufacturing, electronic assembly, automation, and data transmission systems where quality and reliability are critical.

37 female contacts ensure comprehensive connectivity. Steel housing provides mechanical strength and protection. Gold-plated copper alloy contacts enhance signal integrity and corrosion resistance. Wide operating temperature range enhances versatility.

Standardized mounting hardware with 4 to 40 UNC screw lock secures installation. Solder termination ensures firm and durable connection on PCB. Compliant with IEC 60 807 for industrial-grade reliability. Perfect for applications in communication, automation, and data transfer.

Manufactured in Switzerland ensuring high quality standards.

This connector supports industrial, laboratory, communication, and electronic manufacturing applications with precision and reliability. It is a vital component in electronic assemblies requiring stable, high-quality connections. Explore more high-quality connectors and components at EnvMart for your industrial and electronic needs.
