Texas Instruments Controlled Voltage Amplifier 0.25 mV Offset, 85 dB CMRR, 6V 8-Pin SOIC VCA810AID
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 4.9mm |
| Model | VCA810AID |
| Mount Type | Surface |
| Series | VCA810 |
| Output Current | 60mA |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Pin Count | 8 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 4V |
| Supply Current | 24.8mA |
| Vos - Input Offset Voltage | 0.25 mV |
| CMRR - Common Mode Rejection Ratio | 85dB |
Key Features
- Operates at supply voltages between 4 V and 6 V for versatile applications.
- Single channel amplifier designed for surface mount with an 8-pin SOIC package.
- Outputs current up to 60 mA for robust signal drive.
- Functions reliably within the temperature range of -40°C to 85°C.
- Implements variable gain with low input offset, ideal for audio and modulation circuits.
- Compact form factor with length 4.9 mm and height 1.58 mm for easy PCB integration.
- Supply current consumption is 24.8 mA ensuring efficient operation.
Product Description
The Texas Instruments VCA810AID controlled voltage amplifier is a high-performance variable gain amplifier designed for applications requiring precise voltage control. Featuring an input offset voltage as low as 0.25 mV and a common mode rejection ratio (CMRR) of 85 dB, this device ensures minimal distortion and high signal fidelity.
Operating between a minimum supply voltage of 4 V and a maximum of 6 V, the VCA810AID supports demanding environments with an operating temperature range from -40°C to 85°C. It delivers an output current of 60 mA, making it suitable for active audio level compression, synths, and amplitude modulation applications.
The device comes in a compact 8-pin SOIC surface mount package with dimensions measuring 4.9 mm in length and 1.58 mm in height, allowing efficient PCB real estate usage. The supply current is optimized at 24.8 mA to balance power consumption and performance.
Operates in the voltage range of 4 V to 6 V supply. Extremely low input offset voltage of 0.25 mV enhances accuracy. High common mode rejection ratio of 85 dB reduces noise. Single channel design for straightforward integration.
Surface mount 8-pin SOIC package simplifies assembly. Robust output current capability of 60 mA supports active circuitry. Wide operating temperature range from -40°C to 85°C for durability. Compact size fits into dense industrial and laboratory electronic assemblies.
This Texas Instruments voltage controlled amplifier is ideal for industrial, laboratory, electronics manufacturing, and audio signal processing applications where precise amplification and control are paramount.
Explore further voltage amplifier components and other semiconductor devices at EnvMart for your next electronic circuit design.
Explore more products in our Voltage & Current Amplifier category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input offset voltage of this model is as low as 0.25 mV, which enhances accuracy in signal amplification.
The common mode rejection ratio (CMRR) is 85 dB, which helps to reduce noise and distortion in the output signal.
This model can deliver an output current of up to 60 mA, making it suitable for driving active circuitry.
It operates at supply voltages between 4 V and 6 V, allowing for versatile application in various electronic circuits.
This voltage amplifier functions reliably within a temperature range of -40°C to 85°C, suitable for demanding environments.
The dimensions of this model are 4.9 mm in length and 1.58 mm in height, which allows for efficient PCB integration.
It comes in an 8-pin SOIC surface mount package, simplifying assembly and integration into electronic designs.
The supply current consumption is optimized at 24.8 mA, balancing power consumption and performance.
This model is designed as a single channel amplifier, which facilitates straightforward integration into systems.
It is ideal for applications requiring precise voltage control, such as audio level compression, synths, and amplitude modulation.
This model is designed for surface mounting, which is advantageous for compact electronic assemblies.
The VCA810AID is part of the VCA810 series of controlled voltage amplifiers by Texas Instruments.
