Legrand Chassis Mount Transformer Primary Voltage 230 to 400 V Fixing Hole Diameter 11mm Model 0 442 66

Legrand 0 442 66 chassis mount transformer is a high-quality control transformer designed for industrial, laboratory, HVAC, and manufacturing use. It supports a primary voltage range of 230 to 400 V and features an insulated winding for enhanced electrical safety.

This transformer operates with a frequency range between 50Hz and 60Hz and is optimized for maximum operating temperatures up to 50°C, ensuring reliable performance in demanding environments.

Designed for surface mounting using screws, the transformer includes fixing hole diameters of 11mm and terminals equipped with finger protection rated IP2x or xxB for voltages up to 400V. Its construction includes a new design that provides an interference filter between windings to reduce electrical noise.

Compliant with international standards IEC/EN 61558-2-2, IEC/EN 61558-2-4, and IEC/EN 61558-2-6, and approved by UL506 and CSA, it also meets EN 61131-2, EN 60204-1, and EN 60439-1 standards, guaranteeing safety and quality.

Manufactured in France, this transformer is suitable for control and safety isolating applications in industries such as manufacturing, electrical equipment production, and water treatment facilities.

Supports a maximum operating temperature of 50°C. Operates within frequency range of 50Hz to 60Hz. Includes insulated winding for electrical safety. Mounting via screws with 11mm fixing hole diameter. Terminals with finger protection rated IP2x or xxB up to 400V.

Meets IEC/EN 61558-2-2, 2-4, and 2-6 standards. UL506 and CSA approved for safety compliance. Manufactured in France ensuring high quality. Explore more Transformers on EnvMart for a broad selection suited for industrial needs.
