Wurth Elektronik WE-PD 1280 Shielded Wirewound Surface Mount Inductor, 15 μH ±20% 5A 12x12x8mm Ferrite Core 744770115

Wurth Elektronik 744770115 WE-PD 1280 Shielded Wirewound Surface Mount Inductor is an advanced SMD power inductor designed with a ferrite core and wirewound construction. It offers an inductance of 15 μH with ±20% tolerance and supports a maximum DC current of 5 amperes, making it ideal for demanding applications.

This inductor is magnetically shielded, which significantly reduces leakage fields, increasing efficiency and performance in densely packed electronic assemblies. It is housed in a compact 1280 package measuring 12mm in length, 12mm in depth, and 8mm in height, facilitating space-saving on printed circuit boards.

Certified under the automotive AEC-Q200 standard and compliant with IEC 62024-2-2020, RoHS, REACH, and JEDEC JS709B standards, this component ensures high reliability and environmental safety. Its maximum DC resistance is 27mΩ, ensuring low power losses.

The inductor is rated to withstand operating temperatures from -40°C up to 125°C, suitable for industrial, automotive, and consumer electronics environments. The maximum self-resonant frequency of 14.5 MHz enables stable operation in switching regulator circuits and integrated DC/DC converters aiming for high efficiency greater than 86%.

Packaged on tape and reel, this product supports efficient and precise placement using automated pick-and-place machines during PCB assembly. Typical applications include switching regulators with low operating voltages and graphic card power circuits.

The ferrite core and wirewound construction offers low self-losses and high current carrying capability. Magnetic shielding minimizes interference in sensitive circuits. Compact 1280 surface mount package enables efficient PCB layout.

Compliant with automotive and industrial quality standards. Wide operating temperature range supports diverse environments. Ideal for switching regulators and high-efficiency DC/DC converters. Maximum self-resonant frequency of 14.5 MHz for robust high-frequency performance.
