SICK Retroreflective Photoelectric Sensor, Block Style, 22 m Detection Range, PNP Output, IP67 Metal Housing WL24-2B230
Specifications
| Country of Origin | Germany |
|---|---|
| Display | screen |
| Brand | SICK |
| Response time | 500μs |
| Light Source | LED |
| Detection range | 22 m |
| Model | WL24-2B230 |
| IP Rating | IP67 |
| Housing Material | Metal |
| Optional | test input, time delays, contamination signaling at the alarm output, and front-screen heating, also available in a high-power version |
| Output type | PNP |
| Series | W24-2 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -40°C |
| Maximum Current | 100mA |
| DetectIon Type | Retroreflective |
| Terminal type | Terminal Connector |
| Interface Type | M16 |
| Maximum dc Voltage | 30V dc |
| Standards/Approvals | NRKH.E181493 & NRKH7.E181493 |
| Sensor Style | Block |
| Switchable | PNP/NPN and light/dark switching |
| M12 male connector or M16 screw connection | rotatable through 90° |
Key Features
- Rugged metal die-cast zinc housing ensures durability in harsh conditions.
- High immunity to ambient light enhances detection accuracy.
- Operating temperature range from -40°C to 60°C supports extreme environments.
- Response time of 500 microseconds enables fast sensor triggering.
- Switchable PNP/NPN output and light/dark switching increase flexibility.
- IP67 rating provides dust and water resistance for industrial applications.
- Optional front lens heating prevents condensation for reliable use.
- M12 male or M16 screw connector rotatable through 90° for versatile installation.
Product Description
The SICK WL24-2B230 is a robust retroreflective photoelectric sensor featuring a block sensor style with a detection range of 22 meters. It is equipped with a rugged metal die-cast zinc housing rated at IP67, ensuring excellent protection against dust and water ingress, suitable for demanding industrial environments.
This sensor offers high ambient light immunity, allowing reliable detection even in bright or variable lighting conditions. The fast response time of 500 microseconds makes it ideal for automation processes requiring rapid feedback.
Designed with flexibility in mind, the sensor provides switchable PNP/NPN output and light/dark switching modes. Connection options include a rotatable M12 male connector or M16 screw connection, enhancing installation convenience.
Operational temperature ranges from -40°C to 60°C, and optional front-screen heating versions are available to prevent condensation on the front lens, ensuring consistent performance in temperature-fluctuating environments.
Its sturdy metal housing has passed IP 69K testing, guaranteeing long service life and reliability. The sensor meets NRKH.E181493 and NRKH7.E181493 standards, offering safety and quality assurances.
Applications span various industrial, automation, manufacturing, and control gear use cases where precise and durable photoelectric sensing is required. Rugged metal die-cast zinc housing for reliability. High immunity to ambient light for stable detection.
Wide operating temperature range of -40°C to 60°C. Fast response time of 500 microseconds. Switchable output modes: PNP/NPN and light/dark switching. IP67 ingress protection rating. Optional front lens heating to reduce condensation.
Rotatable M12/M16 connectors for flexible installation. Complies with recognized safety and quality standards. Suitable for harsh industrial and automation settings. Explore the SICK brand and related Photoelectric Sensors on EnvMart for industrial automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The WL24-2B230 sensor has a detection range of 22 meters.
It features a fast response time of 500 microseconds, enabling rapid sensor triggering.
This model offers switchable PNP/NPN output and light/dark switching modes for flexibility in application.
The sensor is rated IP67, providing excellent protection against dust and water ingress.
It operates within a temperature range of -40°C to 60°C, suitable for extreme environments.
The housing is made of rugged metal die-cast zinc, ensuring durability in harsh conditions.
It features a rotatable M12 male connector or M16 screw connection for versatile installation.
Yes, optional features include front lens heating to prevent condensation and additional functionalities like test input and time delays.
It meets the NRKH.E181493 and NRKH7.E181493 standards, ensuring safety and quality.
The sensor uses an LED light source for its operation.
The maximum current output is 100mA, suitable for various applications.
This sensor is suitable for various industrial, automation, manufacturing, and control gear applications requiring precise photoelectric sensing.
