Block PCB Transformer 230 V ac Primary Voltage 9 V ac Secondary Voltage 1 VA Power VB 1,0/1/9

Free Delivery in India | Lowest Global Shipping Charges

Block PCB Transformer 230 V ac Primary Voltage 9 V ac Secondary Voltage 1 VA Power VB 1,0/1/9

Name: Block PCB Transformer 230 V ac Primary Voltage 9 V ac Secondary Voltage 1 VA Power VB 1,0/1/9
Brand: Block
SKU: 103732
Price: 20.22 USD
Availability: InStock



Category Power Supplies & Transformers Brand Block Condition New

Specifications

Country of Origin	Germany
Brand	Block
Efficiency	55%
Length	32.3mm
Model	VB 1,0/1/9
Depth	21.8mm
Gross Weight	70g
Width	27.3mm
Mount Type	Pin
Maximum Operating Temperature	70°C
Number of outputs	1
Standards/Approvals	C-UL-US, ENEC 10 (VDE)
Isolation Voltage	5000V
Primary Voltage	230 V ac
Secondary Voltage	9 V ac
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz

Key Features

Designed for PCB mounting with pin type mount.
Compact dimensions of 32.3mm length, 27.3mm width, and 21.8mm depth.
Offers 5000 V isolation voltage ensuring high safety standards.
Efficiency rating of 55% for optimized performance.
Operates reliably between 50Hz and 60Hz frequency range.
Maximum operating temperature of 70°C for stable industrial usage.
Certified with C-UL-US and ENEC 10 (VDE) approvals.
Manufactured in Germany maintaining high quality standards.

Product Description

The Block VB 1,0/1/9 is a PCB Transformer featuring a primary voltage of 230 V ac and a secondary voltage of 9 V ac, designed to deliver 1 VA power with a single output pin configuration. This transformer is engineered for PCB mounting applications with a pin mount type, making it suitable for compact and sensitive electronic circuits.

Measuring 32.3mm in length, 27.3mm in width, and 21.8mm in depth, it offers a space-efficient solution without compromising performance. Equipped with an isolation voltage rating of 5000 V, it provides high safety and electrical isolation, ideal for industrial and commercial electronic assemblies.

With an efficiency of 55%, this transformer balances energy consumption and heat generation, supporting operations up to 70°C maximum temperature. It operates effectively across a frequency range of 50 Hz to 60 Hz, matching common power supply standards worldwide.

Certified to meet prominent international standards, including C-UL-US and ENEC 10 (VDE), the Block VB 1,0/1/9 assures compliance and reliability. Made in Germany, the product reflects rigorous manufacturing quality expected from leading electronics components.

Designed for PCB mounting with pin mount type. Compact dimensions suitable for densely populated boards. High isolation voltage for enhanced safety. 55% efficiency ensures optimized power use. Wide operating frequency and temperature range.

Certified for international safety and quality standards. Manufactured under strict quality controls in Germany.

This PCB transformer is widely used in industrial electronics, power supply circuits, control equipment, and applications requiring dependable electrical isolation and voltage conversion. Its robustness and compact design make it an excellent choice for manufacturing, laboratory setups, and electronic equipment repairs.
