Hanna FC2323 Foodcare pH Electrode for Meat Products with Quick Connect DIN Connector

Name: Hanna FC2323 Foodcare pH Electrode for Meat Products with Quick Connect DIN Connector
Brand: Hanna
SKU: AACMX
Availability: InStock

₹21,952

₹21,902 Save ₹50

Enquire Now

Tax included

Quantity

Specifications

Brand	Hanna
Model	FC2323
Body Material	PVDF
Temperature Sensor	yes
Max. Pressure	0.1 bar
Cable	7-pole\| 1 m (3.3"\|)
Outer Diameter	6 mm
Connector Type	quick connect DIN
Glass Type	low temperature (LT)
Reference Cell Type	single\| Ag/AgCl
Junction Type/Flow Rate	open
Type of Electrolyte	viscolene
Tip / Shape	conic (6 x 10 mm)
Matching Pin	no
Optimum pH Range	pH
Temperature Operating Range	0 to 50C (32 to 122F)
Body Length/Overall Length	36 mm / 164 mm
Amplifier	yes

Key Features

Low Temperature Glass
Stainless Steel Piercing Blade (Optional)

Reference AACMX Category pH Electrodes Brand Hanna

Product Details

The FC2323 is an amplified single junction pH electrode that has a built-in temperature sensor and connects to the meter with a quick connect DIN connector. This type of connector is proprietary to specific meters such as the HI98190.The FC2323 electrode features a food grade plastic PVDF body, an open junction design with viscolene gel electrolyte, a sensing bulb made of low temperature glass, and a conical tip shape. This design consideration, along with the optional stainless steel blades, is ideal for pH measurements in meat and semi-frozen food products. The recommended operating temperature range is from 0 to 50C.
