Patlite LR4 Series Signal Tower Buzzer Unit, Rapid Hi-Lo Sounder (2016 Hz & 3012 Hz), Continuous Beep LR4-302WJBU-RYG
Specifications
| Country of Origin | Indonesia |
|---|---|
| Brand | Patlite |
| Height | 253.5mm |
| Model | LR4-302WJBU-RYG |
| IP Rating | IP65 |
| Mount Type | Bracket, Circular Bracket, Direct, Terminal Block, Cable, Pole, L-Bracket |
| Bulb Type | LED |
| Series | LR4 |
| Maximum Operating Temperature | 50°C |
| Current Type | DC |
| Minimum Operating Temperature | -20°C |
| Base Diameter | 40mm |
| Terminal type | Terminal Block |
| Standards/Approvals | EMC (EN 61000-6-4,EN 61000-6-2), RoHS (EN 50581), UL 508, FCC Part 15 Subpart B Class A, UL Recognized Component (File No.E215660), CSA-C22.2 No. 14, KC (KN 61000-6-4,KN 61000-6-2) |
| Maximum Supply Voltage | 24V dc |
| Housing Colour | Silver |
| Light Effect | Steady, Flashing |
| Sounder Type | Buzzer Unit, Rapid Hi-Lo Sounder (2016 Hz & 3012 Hz), Continuous Beep Sounder (3378 Hz), Sweep Tone Sounder |
| Number of Light Elements | 3 |
| Connection Cable Length | 3.3m |
| Four mounting options | Direct, pole with L-bracket, pole with circular bracket, and pole with folding bracket (Off-white only) |
Key Features
- Features three LED light elements with steady and flashing effects.
- Operates at maximum supply voltage of 24V DC with a current type of DC.
- Includes multiple mounting types including bracket, pole, circular bracket, L-bracket, and terminal block options.
- Sound modules produce loud, omni-directional sound with improved dust and water protection rated at IP65.
- Designed to operate in temperatures ranging from -20°C to 50°C for harsh industrial environments.
- Connection cable length measures 3.3 meters facilitating versatile installation options.
- Complies with various standards and approvals including EMC, RoHS, UL 508, FCC Part 15 Class A, CSA, and KC certifications.
- Constructed with a durable silver housing color enhancing performance and aesthetics.
Product Description
Patlite LR4-302WJBU-RYG Signal Tower Buzzer Unit from the LR4 series is engineered for industrial automation signaling applications requiring reliable audio and visual alerts. This model features a rapid hi-lo buzzer sounder with frequencies of 2016 Hz and 3012 Hz and a continuous beep sounder at 3378 Hz, enabling versatile audio signaling for safety and operational efficiency.
The unit includes three high-intensity LED light elements capable of steady and flashing light effects, delivering clear visual indication under various environmental conditions. It supports multiple mounting configurations such as direct mounting, pole mount with circular or L-brackets, terminal block, and cable connections suitable for installation flexibility.
With a maximum supply voltage of 24V DC and DC current type, the buzzer unit is compatible with standard industrial power systems. Its re-engineered sound module provides a powerful omni-directional sound at 85 dB (measured at 1 meter), with full enclosure ensuring protection against water and dust ingress, certified at IP65.
The operational temperature range between -20°C and 50°C makes it suitable for harsh industrial environments including manufacturing, construction sites, and process automation areas. The silver housing enhances durability and fits well with modern industrial design standards.
This signal tower complies with essential international and regional standards such as EMC (EN 61000-6-4, EN 61000-6-2), RoHS (EN 50581), UL 508, FCC Part 15 Subpart B Class A, UL Recognized Component, CSA-C22.2 No. 14, and KC (KN 61000-6-4, KN 61000-6-2) ensuring safety and regulatory conformity.
Features three LED light elements with steady and flashing effects. Multiple mounting options for flexible installation. Rapid hi-lo sounder and continuous beep sounder for audible signaling. IP65 rated water and dust protection for durability.
Operates on 24V DC supply voltage with DC current. Suitable for temperatures from -20°C to 50°C. High sound level of 85 dB at 1m for clear alerts. Silver robust housing design for harsh environments.
This Patlite signal tower buzzer unit is ideal for industrial, manufacturing, laboratory, and HVAC applications where multi-function signaling is crucial. It supports enhanced safety and operational efficiency in demanding automation environments. Explore more high-quality Signal Towers and electronic signaling devices in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 24V DC.
This unit produces a sound level of 85 dB when measured at 1 meter.
It supports multiple mounting options including direct mounting, pole mount with circular or L-brackets, terminal block, and cable connections.
It operates effectively in temperatures ranging from -20°C to 50°C.
This model complies with EMC, RoHS, UL 508, FCC Part 15 Class A, CSA, and KC certifications.
The unit features three high-intensity LED light elements.
It produces a rapid hi-lo sound at frequencies of 2016 Hz and 3012 Hz, as well as a continuous beep sound at 3378 Hz.
The unit has an IP65 rating, providing protection against dust and water ingress.
The connection cable length measures 3.3 meters, allowing for versatile installation options.
The height of this model is 253.5 mm.
The LED elements can produce both steady and flashing light effects.
The housing color of this unit is silver.
