Molex Micro-Lock Plus Male Connector Housing 1.25 mm Pitch 6 Way 1 Row Straight 505565-0601
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 9.5mm |
| Width | 6.1mm |
| Mount Type | Surface |
| Housing Material | Polyester |
| Series | Micro-Lock Plus |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| For Use With | 505431 Micro-Lock PLUS Terminal |
| Number of Contacts | 6 |
| Connector Gender | Male |
Key Features
- Connector housing designed for Micro-Lock Plus series.
- 1.25 mm pitch with 6 contact positions.
- Straight orientation suitable for surface mount applications.
- Durable polyester housing material for high-temperature tolerance.
- Compact size with 9.5 mm length and 6.1 mm width.
- For use with 505431 Micro-Lock PLUS Terminal.
- Reliable locking mechanism for secure connections.
- Ideal for automotive and industrial applications including steering wheels and sensors.
Product Description
Molex 505565-0601 Micro-Lock Plus Male Connector Housing is a high-quality connector housing designed with a 1.25 mm pitch, 6-way contact configuration in a single row, intended for reliable wire-to-board applications. The compact 9.5 mm length and 6.1 mm width make it suitable for space-constrained electronic assemblies.
Constructed with a durable polyester housing material, this connector offers excellent mechanical and electrical reliability along with high-temperature tolerance, meeting stringent industrial and automotive demands. Its straight orientation and surface mount design allow for versatile PCB integration with a positive locking mechanism for secure mating.
This connector housing is optimized for use with the 505431 Micro-Lock PLUS Terminal, providing excellent compatibility within the Micro-Lock Plus series.
Applications include automotive systems such as steering wheels, paddle shifts, combination switches, headlight assemblies, and industrial automation, consumer electronics, gaming machines, drones, air conditioning units, laser printers, and vacuum cleaners.
Connector housing designed for Micro-Lock Plus series. 1.25 mm pitch with 6 contact positions. Straight orientation suitable for surface mount applications. Durable polyester housing material for high-temperature tolerance.
Compact size with 9.5 mm length and 6.1 mm width. For use with 505431 Micro-Lock PLUS Terminal. Reliable locking mechanism for secure connections. Ideal for automotive and industrial applications including steering wheels and sensors.
Manufactured in Japan ensuring quality and consistency.
Choose this connector for reliable, space-efficient PCB connector housing needs in automotive, consumer electronics, and industrial automation sectors. Browse more from the Molex Micro-Lock Plus series on EnvMart for comprehensive connectivity solutions.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Molex Micro-Lock Plus Male Connector Housing features a pitch size of 1.25 mm.
This model supports 6 contact positions in a single row configuration.
The connector housing has a length of 9.5 mm and a width of 6.1 mm.
It is designed for surface mount applications.
The housing is constructed from durable polyester material, providing high-temperature tolerance.
It is optimized for use with the 505431 Micro-Lock PLUS Terminal.
The connector housing has a straight orientation.
This model is manufactured in Japan.
It is ideal for automotive applications such as steering wheels, paddle shifts, and industrial automation.
This connector housing features a single row design.
The connector gender of this housing is male.
This housing is part of the Micro-Lock Plus series by Molex.
