Molex Micro-Lock Plus Male Connector Housing 1.25 mm Pitch 6 Way 1 Row Straight 505565-0601
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Molex |
| Orientation | Straight |
| Length | 9.5mm |
| Width | 6.1mm |
| Mount Type | Surface |
| Housing Material | Polyester |
| Series | Micro-Lock Plus |
| Number of Rows | 1 |
| Pitch | 1.25mm |
| For Use With | 505431 Micro-Lock PLUS Terminal |
| Number of Contacts | 6 |
| Connector Gender | Male |
Key Features
- Compact design ideal for signal wire-to-board applications.
- High reliability in electrical and mechanical connections.
- Constructed with durable polyester housing material.
- Color-coded for easy assembly and identification.
- Suitable for automotive and industrial automation uses.
- Surface mount type with straight orientation.
- Compatible with 505431 Micro-Lock PLUS Terminal.
- Manufactured in Japan maintaining quality standards.
Product Description
Molex 505565-0601 Micro-Lock Plus Male Connector Housing features a 1.25 mm pitch, 6 contacts in a single row straight configuration. This connector housing is designed for surface mounting and is made of durable polyester material, providing excellent electrical and mechanical reliability for compact applications.
This housing is part of the Micro-Lock Plus series, engineered to meet stringent automotive and industrial requirements. Its color-coded design aids assembly and reduces wiring errors.
The 505565-0601 model is compatible with the 505431 Micro-Lock PLUS Terminal, enabling robust connections for various electronics components.
Typical applications include automotive systems such as steering wheel controls, paddle shifters, combination switches, and various internal connections in industrial automation and consumer electronics.
Compact and reliable wire-to-board connector housing. Durable polyester housing material ensures longevity and performance. 1.25 mm pitch and 6 way configuration supports high-density wiring. Surface mount direct to PCB with straight orientation.
Designed to meet automotive electrical standards. Supports various industrial and consumer applications. Color-coded options improve assembly accuracy. Manufactured in Japan for consistent quality.
This connector housing is essential for industrial, automotive, and consumer electronic assemblies requiring compact, high-reliability connectors. Explore other PCB connectors and wire housings in EnvMart's Electronics Components category for complementary solutions.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of this connector housing is 1.25 mm.
This model supports 6 contacts in a single row configuration.
It utilizes surface mounting for installation on PCBs.
The orientation of this connector housing is straight.
The housing is constructed from durable polyester material.
It is compatible with the 505431 Micro-Lock PLUS Terminal.
The housing has a length of 9.5 mm and a width of 6.1 mm.
This model belongs to the Micro-Lock Plus series.
It is suitable for automotive systems, industrial automation, and consumer electronics applications.
It is manufactured in Japan, ensuring consistent quality standards.
The color-coded design aids in assembly and reduces wiring errors.
The connector gender of this model is male.
