Bourdon 100 mm G 1/2 Bottom Pressure Gauge 16 bar MEX5-D30.B24

The Bourdon MEX5-D30.B24 is a stainless steel industrial pressure gauge featuring a 100 mm nominal dial size and bottom entry connection size of G 1/2, designed for accurate pressure measurement up to 16 bar with ±1% accuracy. This pressure gauge is engineered for robust performance in environments involving corrosive gases and liquids.

Featuring a white dial face with black lettering and a black plastic pointer, it ensures clear readability. The gauge glass window is made from a high-quality instrument glass equipped with an elastomer seal and a blow-out device to enhance operator safety.

This model complies with the EN 837-1 Class 1.0 standards and carries approvals such as Material certificate 3.1 EN10204, Lloyds Register Approval, EN 60529, and ATEX II2GDc-IM2c, reflecting its suitability for demanding industrial use. The IP65 rating provides reliable protection against dust and water ingress, enhancing durability.

The pressure connection is a 1/2 inch NPT male thread and the connection location is at the bottom entry, suitable for installations requiring this configuration. Its maximum operating temperature is 70°C, supporting diverse industrial environments.

Typical applications include food and beverage processing, laboratory and medical instrumentation, oil and gas, chemical processing, water and wastewater treatment, energy generation, transportation, and logistics sectors.

Constructed with stainless steel for corrosion resistance. Accurate pressure measurement class 1.0. IP65 ingress protection rating. Complies with multiple international approvals and standards. Suitable for corrosive gases and liquids environments.

Equipped with safety blow-out device glass window. Bottom connection entry with G 1/2 size. Wide industrial application scope. Explore Bourdon Pressure Gauges and measuring instruments categories on EnvMart for more industrial solutions.
