Molex Nano-Fit Series PCB Header, Right Angle, 4 Contacts, 2.5 mm Pitch, 2 Row, Shrouded 105314-1204
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 250, 250V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 6.5A |
| Mount Type | Through Hole |
| Contact Material | Brass |
| Series | Nano-Fit |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.5mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 3.2mm |
Key Features
- Right angle through-hole mounting simplifies PCB layout and saves board space.
- Features a robust shrouded design for enhanced contact protection during use.
- Supports a 6.5A current rating, suitable for demanding industrial and automotive applications.
- Gold-plated brass contacts reduce contact resistance and ensure durable connections.
- Positive lock mechanism prevents accidental disconnection for extra reliability.
- Compatible with a wide temperature range from -40°C to 105°C.
- Designed for wire-to-board assembly in telecom, healthcare, and consumer electronics.
Product Description
Molex 105314-1204 Nano-Fit Series PCB Header is engineered for precision and reliability in modern electronic assemblies, featuring a right angle, through-hole configuration. The header is built with 4 gold-plated male contacts arranged in two rows with a compact 2.5 mm pitch. Its shrouded housing enhances operational security, safeguarding contacts during installation and subsequent use.
With a robust 6.5A current rating and support for up to 250V AC/DC, this header fits demanding industrial, automotive, and telecommunications environments. Brass contacts with gold plating offer low contact resistance and reliable signal transmission, ensuring stability even in high-vibration settings. The right angle design optimizes space on the PCB, allowing for efficient layout and connectivity solutions in constrained applications.
Molex’s positive-lock mechanism provides an extra layer of reliability, preventing unintentional disconnections during operation. Termination is achieved via soldering, making integration easy for a variety of PCB thicknesses, including 1.60 mm and 2.40 mm. Operating across temperatures from -40°C to +105°C, the Nano-Fit Series is suitable for cabinets, networking hubs, automotive lighting systems, refrigeration, laundry equipment, and healthcare IT devices.
Right angle, through-hole assembly improves PCB space utilization. Shrouded contacts maximize protection in industrial and automotive environments. Gold-plated brass engineering delivers robust, consistent connectivity. 6.5A current and 250V voltage rating support high-demand applications.
Wide temperature compatibility, suitable for diverse industrial conditions. Positive locking for secure installation and operation. Easy wire-to-board integration for telecom, healthcare, and consumer electronics use cases.
This high-quality Molex PCB header is RoHS compliant and is built for engineers seeking reliable connectivity and space-saving solutions. Applications include industrial automation, medical electronics, networking equipment, and automotive assemblies. Browse more Molex Nano-Fit series PCB Headers in the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 6.5A, making it suitable for demanding applications in industrial and automotive environments.
It has a voltage rating of 250V AC/DC, allowing it to operate effectively in various electronic applications.
The termination type for this unit is solder, facilitating easy integration with different PCB thicknesses.
The contacts are arranged with a pitch of 2.5 mm, optimizing space on the PCB.
This model features 4 male contacts arranged in 2 rows, providing a compact connection solution.
It operates effectively within a temperature range of -40°C to +105°C, suitable for various industrial conditions.
The header is designed with a right angle orientation, which helps in saving board space during layout.
The contacts are made of brass and are gold-plated, which reduces contact resistance and enhances connectivity.
This unit features a shrouded design, which provides enhanced protection for the contacts during use.
It utilizes a wire-to-board connector system, making it suitable for various electronic applications.
The tail pin length is 3.2 mm, which aids in secure soldering to the PCB.
The country of origin for this PCB header is China.
