Harting Hood Frame, Die Cast Zinc, 1 Way, Top Cable Entry, HAN Modular Series, 10B Size, Black, Model 09140000304

The Harting 09140000304 hood frame serves as an essential component in the assembly of heavy duty industrial power connectors, providing a robust and reliable structure for modular and high-performance electrical connections. This model, part of the HAN Modular Series, is constructed from die cast zinc, ensuring excellent mechanical durability even in demanding industrial and automation environments. Its one-piece frame, specifically designed for 1-way configurations, is engineered for use with heavy duty power connector assemblies and integrates seamlessly into various control panels and power distribution units.

The design features a top cable entry, making it ideal for space-constrained installations where easy access to wiring is required. The frame supports wire sizes ranging from 4mm² to 10mm², addressing a broad array of power transmission and signal lines. The 10B size conforms to industry recognition, supporting global compatibility and straightforward replacement or integration with existing HAN Modular solutions. This modularity allows the connector assembly to adapt flexibly to application-specific requirements, such as control, signal, and power lines consolidated within a single robust interface.

The Harting hood frame includes an efficient grounding system following VDE standards, critical for maintaining electrical safety and system integrity in industrial operations. It is rated for more than 500 mating cycles, granting the reliability necessary for frequent connect-disconnect and maintenance operations. Its black finish and precise engineering contribute to both professional appearance and performance, while the die cast zinc construction ensures longevity in challenging environments subject to shock, vibration, and environmental contaminants.

Suitable for use with standard HAN Modular hoods and housings, the Harting 09140000304 enables users to implement tailored connector configurations for various industrial needs. Its single contact position and robust mechanical locking facilitate dependable connections for applications such as machinery, automation systems, heavy equipment, and distribution boards in manufacturing, energy, and infrastructure environments.

Engineers and installers benefit from the straightforward installation, dependable material quality, and the flexibility to match demanding performance specifications. This hood frame is a preferred solution in sectors where modular connectivity and reliable performance are mission-critical, such as industrial automation, power plants, railway systems, and heavy manufacturing.
