Phoenix Contact SPT 1.5/5-H-3.5 PCB Terminal Block, 5 Contacts, 3.5 mm Pitch, Straight Wave Soldering Mount, 200V 1990766

Phoenix Contact 1990766 SPT 1.5/5-H-3.5 Series PCB Terminal Block is engineered for reliable wave soldering mount applications, featuring 5 contacts in a single row and a 3.5 mm pitch. This terminal block is ideal for connecting rigid or flexible cables, accommodating circuit layouts that require high-density connection points.

With a current rating of 17.5A and voltage up to 200V, the terminal block is suitable for a wide range of industrial and electronic applications. The device incorporates a polyamide housing for superior insulation and mechanical robustness, ensuring reliable performance even in challenging operating environments.

The product's straight orientation allows for efficient space management within PCB assemblies, while the wave soldering mount provides strong mechanical retention and electrical connectivity to the printed circuit board. It is designed for plug-and-play technology, supporting both rigid and flexible cables with or without ferrule, and offering versatility for diverse wiring setups.

As part of Phoenix Contact’s COMBICON SPT series, the terminal block facilitates connections vertically or horizontally, making it adaptable to varying board layouts. The 3.5 mm grid system also supports the integration of complementary 5 mm grid components, giving engineers flexibility in circuit design.

Compliances include EU RoHS and cULus recognition, confirming suitability for industrial, laboratory electronics, automation, test systems, and demanding manufacturing environments.

Applications for this terminal block extend to PCB connectors in power distribution modules, sensor interfaces, control electronics, process instrumentation, and industrial automation equipment.
