pH and EC Transmitter with Isolated Output- 4 - 20 mA (active) - HI98143

The HI98143 is part of a family of blind transmitter that can be used in water treatment and hydroponic applications. These meters have inputs for both pH and EC probes. The pH probe input uses a common BNC connector while EC has a direct wire connection for use with Hanna’s EC probes that incorporate an NTC sensor for temperature compensation. The HI98143 is available in four models based on the analog output signal required. Blind transmitter for pH and EC (up to 10 mS/cm) Choice of analog output in voltage or current Powered or loop powered analog outputs Direct Connection Direct connection of the probes to the transmitter assures a positive electrical connection with no signal loss. This transmitter is ideal for remote process control applications. Output Signals Four models are availa Features: SKU:HI98143-22,Analog Output:HI98143-01 0-1 V HI98143-04 0-4 V HI98143-20 4-20 mA (passive) HI98143-22 4-20 mA (active),Cell Type:4-ring EC probes,Dimensions:160 x 105 x 31mm (6.3 x 4.1 x 1.2”),EC Accuracy:±2% f.s.,EC Calibration:0 (offset) and 5 mS/cm (slope) trimmers,EC Range:0 to 10 mS/cm,EC/TDS Probe:Four (ring) pole probe with built in NTC sensor,EC/TDS Temperature Compensation:Automatic from 0 to 60 ºC,Environment:0 to 50 °C (32 to 122 °F) - max 95% RH non-condensing,IP Rating:IP54,Power Supply:12-24 Vdc,Temperature Correction Coefficient:ß=2%/ ºC,Weight:280 g (9.9 oz.),pH Accuracy:±0.5% f.s.,pH Calibration:Manual, 2 point, through trimmers,pH Range:0 to 14
