Labtron Bekk Smoothness Tester TP-L20 image-1

Free Delivery in India | Lowest Global Shipping Charges

Bekk Smoothness Tester TP-L20

Name: Bekk Smoothness Tester TP-L20
Brand: Generic Brand
SKU: ADHPK
Price: 69.5 USD
Availability: InStock



SKU ADHPK Category Testing Instruments Brand Generic Brand Condition New

Specifications

Country of Origin	UK
Accuracy	±0.1 s within 300 s
Brand	Generic Brand
Power Supply	AC 220 V ± 10 % / 50 Hz
Net Weight	30 KG
Model	TP-L20
Type of Product	Testing Instrument
Dimension (L x W x H)	325 x 390 x 430 mm
Contact Pressure	100 ± 2 kPa
Measuring Scope	(1 to 9999) s / divided into (1 to 15) s / (15 to 300) s / (300 to 9999) s / automatic (no more than 200 s)
Vacuum System Volume (ml)	Bigger volume — 380 ± 1 / Smaller volume — 38 ± 1
Vacuum Scope	I) 50.66 to 48.00 / II) 50.66 to 48.00 / III) 50.66 to 29.33 / Automatic — No limit
Air Volume (50.66 kPa down to 48.00 kPa)	Big vacuum volume — 10.00 ± 0.20 ml / Small vacuum volume — 1.00 ± 0.05 ml

Key Features

Fast measurement mode
Adopted with vacuum sealed plastic & advanced sealing technology
7 inch colored touch screen
CAM & spring structure design with 100 N pressure
Data communication via PC software
USB cable connection

Product Description

The Bekk Smoothness Tester TP-L20, with a microprocessor-controlled system, is used for the determination of smoothness of paper and cardboard using the ‘Bekk Method’. It is equipped with a high-precision sensor and an imported oil-free vacuum pump to ensure smooth and reliable operation. The test results generated with the Bekk Smoothness Tester have shown strong correlation with print smoothness evaluation using offset ink.

Applications:

The Smoothness Tester is used for testing the smoothness of coated label papers, sheets, smooth-textured papers, printing papers, photographic papers, and more in the paper, printing, and packaging industries.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The measuring scope of this model ranges from 1 to 9999 seconds, with divisions into intervals of 1 to 15 seconds, 15 to 300 seconds, and 300 to 9999 seconds, including an automatic mode for times not exceeding 200 seconds.

The accuracy of the Bekk Smoothness Tester TP-L20 is ±0.1 seconds within a measurement time of 300 seconds.

The dimensions of the Bekk Smoothness Tester TP-L20 are 325 mm in length, 390 mm in width, and 430 mm in height.

The contact pressure for the Bekk Smoothness Tester TP-L20 is 100 ± 2 kPa.

This unit requires an AC power supply of 220 V ± 10 % at a frequency of 50 Hz.

The net weight of this model is 30 kg.

The Bekk Smoothness Tester TP-L20 features two vacuum system volumes: a bigger volume of 380 ± 1 ml and a smaller volume of 38 ± 1 ml.

The vacuum scope for this model includes three levels: I) 50.66 to 48.00 kPa, II) 50.66 to 48.00 kPa, and III) 50.66 to 29.33 kPa, with an automatic mode that has no limit.

Data communication for the Bekk Smoothness Tester TP-L20 is facilitated via PC software using a USB cable connection.

This model utilizes a microprocessor-controlled system along with a high-precision sensor and an oil-free vacuum pump to ensure reliable operation during measurements.

The country of origin for the Bekk Smoothness Tester TP-L20 is the UK.
