Multi-viewing Biological Microscope EMB-A13

Name: Multi-viewing Biological Microscope EMB-A13
Brand: Generic Brand
SKU: ADGGW
Price: 69.5 USD
Availability: InStock



SKU ADGGW Category Microscopes Brand Generic Brand Condition New

Specifications

Country of Origin	UK
Brand	Generic Brand
Dimension	74 × 36 × 44 cm
Power	85V to 265V
Model	LMB-A13
Weight	16.5 kg
Type of Product	Microscope
Condenser	Abbe type N.A.-125 with Iris Diaphragm
Pointer	3W LED
Illumination	Built-in Koehler illuminator system — 6V/20W with Adjustable brightness
Focusing	Coaxial coarse and fine focusing adjustment / fine division 0.002 mm
Eyepiece	WFIOX/20 mm
Objective	Infinite Plan Objectives (5pcs) — 4x /10x / 20x / 40x(s / oil) / 100x(s / oil)
Viewing Head	Dual Siedentopf-type Binocular head Inclination — 30° Rotation — 360°
Nosepiece	Quintuple
Stage	Double layers mechanical stage — 190 × 140mm Moving stage — 78 × 55 mm

Key Features

Enhanced with an anti-fungal system
Utilizes coaxial adjustment system for both coarse and fine focusing
Upgraded with rack and pinion mechanism
Designed with a revolving mechanism with five click-stop positions
Featuring multiple ball bearings for smooth operation
Integrated Koehler illuminator system to adjust brightness and field
diaphragm

Product Description

Multi-Viewing Biological Microscope LMB-A13 is equipped with dual binocular viewing heads, allowing multiple observers to view the specimen simultaneously. With a 30° inclination and 360° rotation of the viewing head, it offers observers flexible angles to examine specimens. Integrated with a double-layer mechanical stage with a removable slide holder. Its user-friendly controls for adjusting focus, magnification, illumination, and other parameters make it accessible to both new users and experienced researchers.

Applications:

The Multi-Viewing Biological Microscope finds extensive use across various fields including pathology, medical diagnostics, molecular biology, and numerous scientific institutions for both research and demonstration purposes.

Standard Accessories:

6V/20W Spare Halogen Lamp
BGX 1-20 (0.5A) Fuse
Blue Ground Glass Filter
Dust Cover
English Manual
Immersion Oil

Optional Accessories:

Phase Contrast Kit

Multi-viewing Biological Microscope EMB-A13

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The Multi-Viewing Biological Microscope LMB-A13 features Infinite Plan Objectives with magnifications of 4x, 10x, 20x, 40x (spring/oil), and 100x (spring/oil).

It is equipped with a built-in Koehler illuminator system that includes a 6V/20W halogen lamp with adjustable brightness.

The dimensions of the microscope are 74 × 36 × 44 cm, and it weighs 16.5 kg.

It features a dual Siedentopf-type binocular head that can be inclined at 30° and rotated 360° for flexible viewing angles.

The microscope includes a double-layer mechanical stage measuring 190 × 140 mm, with a moving stage of 78 × 55 mm.

It is equipped with an Abbe type condenser with a numerical aperture of 1.25 and an iris diaphragm for controlling light.

Standard accessories include a 6V/20W spare halogen lamp, a BGX 1-20 (0.5A) fuse, a blue ground glass filter, a dust cover, and an English manual.

Yes, it is suitable for various fields including pathology, medical diagnostics, molecular biology, and is commonly used in scientific institutions for research and demonstration.

An optional accessory for this microscope is a phase contrast kit, which can enhance its functionality for specific applications.

The microscope operates with a power supply range of 85V to 265V.

The Multi-Viewing Biological Microscope LMB-A13 is manufactured in the UK.
