Labtron LSAE-A13 Semi-Automated Electrolyte Analyzer image-1

Free Delivery in India | Lowest Global Shipping Charges

Semi-Automated Electrolyte Analyzer ESAE-A13

Name: Semi-Automated Electrolyte Analyzer ESAE-A13
Brand: Generic Brand
SKU: ADBQF
Price: 69.5 USD
Availability: InStock



SKU ADBQF Category Electrolyte Analyzer Brand Generic Brand Condition New

Specifications

Relative Humidity	≤ 85%
Brand	Generic Brand
Power Supply	100 to 240V / 50/60 Hz
Model	LSAE-A13
Sample Type	Plasma / Serum / Whole blood / Urine / CSF
Ambient Temperature (ºC)	5°C to 40°C
Sample Volume	65 to 150 µL
Test Range	K⁺ - 0.50 to 15.00 mmol/L / Na⁺ - 20.0 to 200.0 mmol/L / Cl⁻ - 20.0 to 200.0 mmol/L / Ca²⁺ - 0.10 to 5.00 mmol/L / Li⁺ - 0.00 to 3.00 mmol/L / pH - 6.0 to 9.0 / TCO₂ - 6.0 to 50.0 mmol/L
Test Parameters	K⁺ / Na⁺ / Cl⁻ / Ca²⁺ / Li⁺ / pH / TCO₂
Test Resolution	K⁺ - 0.01 mmol/L / Na⁺ - 0.1 mmol/L / Cl⁻ - 0.1 mmol/L / Ca²⁺ - 0.01 mmol/L / Li⁺ - 0.01 mmol/L / pH - 0.01 / TCO₂ - 0.1 mmol/L
Test Precision	K⁺ - ≤ 1.0% / Na⁺ - ≤ 1.0% / Cl⁻ - ≤ 1.0% / Ca²⁺ - ≤ 1.5% / Li⁺ - ≤ 1.5% / pH - ≤ 1.0% / TCO₂ - ≤ 3.0%
Sample Load	40 Samples/Hour (with TCO₂) / 60 Samples/Hour (without TCO₂)
Sample Loader	25 Positions / 40 Positions
Sample Tube	Primary tube or cuvette
Small Sampler Dimension	347 × 277 × 451 mm
Big Sampler Dimension	570 × 425 × 380 mm
Mainframe Dimension	337 × 192 × 402 mm
Small Sampler Weight	6.5 kg
Big Sampler Weight	10 kg
Mainframe Weight	17 kg

Key Features

Self-diagnostic and self-adjustment
Alarm for low reagent volume
Real-time testing status
STAT capability for single/multiple sample tests
Liquid level detection
Probe collision protection
Built-in bar code scanner
All-in-one maintenance mode
Visible QC graph for storage, transfer, and printing

Product Description

Semi-Automated Electrolyte Analyzer LSAE-A13 can process up to 60 samples per hour, supporting both primary tubes and cuvettes. Liquid level detection and probe collision protection improve reliability during auto-sampling. With rapid testing capability, completing ISE tests in just 25 seconds, it ensures high throughput. Its electrodes provide long lifespan, anti-jamming, and anti-pollution properties. Our analyzer, with a lightweight mainframe and samplers, allows for easy integration into various laboratory settings.

Applications:

Our Semi-Automated Electrolyte Analyzer is used in clinical laboratories to measure and analyze key electrolytes such as potassium, sodium, and chloride in samples like plasma, serum, whole blood, urine, and cerebrospinal fluid for diagnostic purposes.

Standard Accessories:

Electrode set
internal thermal printer
external sample barcode scanner
auxiliary pump tube × 2
pump tube (2.4 × 5.6 BPT) × 3
reagent pack connector
Allen key
fuse × 2
printer paper (30 × 57) × 3
electrode O-ring (Φ2.6 × 1.9) × 5
syringe (50ml)
Taike tube (G2.5 × 0.8) 200mm
long needle for blockage elimination (Φ0.6 × 160)
manual-probe tie-in × 2
bottle cap (with a small hole) for TCO₂ reaction solution
tubes for auto sampler (12.7mm × 100mm)
tubes for auto sampler (12.7 × 75mm)
cuvettes for auto sampler
auto probe tie-in for auto sampler × 2
data cable for auto sampler
refill solution for ISE electrodes (0.8ml) × 5
refill solution for reference electrode (20ml)
calibration standard solution
de-proteinizer
electrolytes quality control (high/medium/low)
conditioning solution (0.8ml) × 5
TCO₂ reagent (50ml) × 3
TCO₂ quality control (H:1ml × 5; L:1ml × 5)
small auto sampler (25 sample positions) with built-in barcode scanner
big auto sampler (40 sample positions) with built-in barcode scanner
K electrode
Na electrode
Cl electrode

Optional Accessories:

Small auto sampler (25 sample positions)
Ca electrode
pH electrode
Li electrode
ref electrode
refill solution for ref electrode
refill solution for ISE electrodes (K/Na/Cl/Ca/pH)
refill solution for Li electrode
cleaning solution
conditioning solution
calibration standard solution for ISE
calibration standard solution for ISE + Li
reagent pack connector
TCO₂ reagent-reaction solution (50ml)
TCO₂ quality control (high/low)
de-proteinizer (including diluter) for electrodes
electrolytes quality control (high/medium/low)
selective coefficient calibrator for Li electrode
pump tube
printer paper
auto-probe tie-in
O-ring for electrode
cuvettes for auto sampler × 1000

Semi-Automated Electrolyte Analyzer ESAE-A13

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model can process up to 60 samples per hour without TCO₂ and 40 samples per hour with TCO₂.

It is designed to analyze plasma, serum, whole blood, urine, and cerebrospinal fluid (CSF).

The test range for potassium is from 0.50 to 15.00 mmol/L.

It operates on a power supply of 100 to 240V at 50/60 Hz.

The operating ambient temperature range is from 5°C to 40°C.

The sample volume required for testing ranges from 65 to 150 µL.

The mainframe dimensions are 337 × 192 × 402 mm.

The test precision for sodium is ≤ 1.0%.

Included accessories are an electrode set, internal thermal printer, external sample barcode scanner, auxiliary pump tubes, and various calibration solutions.

The test resolution for chloride is 0.1 mmol/L.

It features liquid level detection and probe collision protection to enhance reliability during auto-sampling.
