Alpha Wire Alpha Essentials Communication & Control Control Cable 6 Cores 22 AWG Screened 305 m 300V 1296C SL001
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 300V |
| Display | Screen |
| Brand | Alpha Wire |
| Model | 1296C SL001 |
| Cable Length | 305m |
| Series | Alpha Essentials Communication & Control |
| Outside diameter | 5.87mm |
| Maximum Operating Temperature | 80°C |
| Number Of Cores | 6 |
| Conductor Material | Tin Copper Wire |
| Minimum Operating Temperature | -20°C |
| Jacket Material | Polyvinyl Chloride |
| Standards/Approvals | UL, CSA, CE |
| Jacket Colour | Grey |
| Fire Behaviour | Flammability Test: VW-1 |
| American Wire Gauge | 22AWG |
| Screened/Unscreened | Screened |
| Number of Strands | 7 |
| Core Strands | 7 x 30AWG |
| Size of Strands | 30AWG |
| Fire BehaviourFlammability Test | VW-1 |
| Flammability Test | VW-1 |
Key Features
- Screened construction maintains signal integrity over long cable runs.
- Tin copper 7-strand conductors provide enhanced flexibility and corrosion resistance.
- Rated for operation up to 80°C suitable for elevated temperature environments.
- Grey polyvinyl chloride (PVC) jacket provides mechanical protection and electrical insulation.
- Complies with UL, CSA, and CE standards ensuring recognized safety approvals.
- VW-1 flammability rating enhances fire safety compliance for industrial use.
- Striped core color coding simplifies installation and system identification.
- Recommended minimum bend radius is ten times the cable diameter to prevent damage.
Product Description
Alpha Wire 1296C SL001 Control Cable from the Alpha Essentials Communication & Control Series is a screened 6-core cable with 22 AWG tin plated copper conductors, designed specifically for industrial control and communication applications. This cable supports a voltage rating of 300V and is suitable for operation in temperature ranges from -20°C to 80°C. The grey polyvinyl chloride (PVC) jacket provides robust mechanical protection and electrical insulation, making it ideal for factory automation and control panel wiring.
The cable's screened construction uses a laminated aluminium/mylar foil with 25% minimum overlap and a 22 AWG tin copper drain wire to ensure excellent signal integrity by reducing electromagnetic interference. Each conductor consists of seven 30 AWG strands, enhancing flexibility while maintaining low resistance essential for control circuits.
The Alpha Wire 1296C SL001 cable complies with industry standards UL, CSA, and CE and holds a VW-1 flammability rating, meeting safety requirements for commercial and industrial installations. Striped core color coding aids in quick identification during wiring tasks. For installation, a minimum bend radius of ten times the overall diameter is recommended, with a maximum pull tension of 38 lbs to prevent damage to the internal conductors.
This cable is suited for machine control wiring in factory automation, relay cabinet wiring, distributed I/O and sensor networks, instrumentation requiring screened cables, and building services control and signaling systems. Supplied in long 305-meter continuous lengths on industrial spools, it facilitates ease of installation with reduced jointing.
Screened design ensures protection against electromagnetic interference. Flexible tin copper 7-strand conductors reduce corrosion risk. Supports a 300V voltage rating for common control circuit applications. Suitability for use in ambient temperatures up to 80°C.
Grey PVC jacket offers durability and mechanical protection. Complies with UL, CSA, and CE safety standards. VW-1 flammability rating for enhanced fire safety. Striped core color coding for simplified system identification.
Recommended minimum bend radius: 10 x diameter to avoid damage. Maximum pull tension during installation: 38 lbs. Continuous 305-meter length reduces jointing in installations. Explore a wide range of industrial and Control Cables at EnvMart for all your electrical wiring requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Alpha Wire 1296C SL001 control cable has a voltage rating of 300V, making it suitable for common control circuit applications.
This model can operate at a maximum temperature of 80°C, which is suitable for elevated temperature environments.
The cable is supplied in a continuous length of 305 meters, which facilitates ease of installation with reduced jointing.
The cable features a grey polyvinyl chloride (PVC) jacket for mechanical protection and electrical insulation, and the conductors are made of tin copper wire.
The minimum operating temperature for this cable is -20°C, allowing it to function effectively in colder environments.
This control cable has 6 cores, which allows for multiple signal and power transmission paths.
The cable has a VW-1 flammability rating, enhancing its fire safety compliance for industrial use.
The outside diameter of the cable is 5.87 mm, which is important for installation and compatibility with connectors.
Each conductor consists of seven 30 AWG strands of tin copper wire, providing enhanced flexibility and low resistance.
This cable complies with UL, CSA, and CE standards, ensuring recognized safety approvals for its use in various applications.
The recommended minimum bend radius for this cable is ten times the overall diameter to prevent damage during installation.
This control cable is suited for machine control wiring in factory automation, relay cabinet wiring, and distributed I/O and sensor networks.
