Bivar 2.6 V 78 mW 1005 Surface Mount Red LED 631nm Dominant Wavelength SM0402RC

Free Delivery in India | Lowest Global Shipping Charges

Bivar 2.6 V 78 mW 1005 Surface Mount Red LED 631nm Dominant Wavelength SM0402RC

Name: Bivar 2.6 V 78 mW 1005 Surface Mount Red LED 631nm Dominant Wavelength SM0402RC
Brand: Bivar
SKU: 420334
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Bivar Condition New

Specifications

Country of Origin	China
Brand	Bivar
Model	SM0402RC
Packaging	Tape & Reel
Mount Type	Surface
LED Color	Red
Series	SM0402RC
Maximum forward current	30mA
Viewing angle	130 °
Package Type	1005
Standards/Approvals	RoHS Compliant
LED Colour	Red
Dominant Wavelength	631nm
Forward Voltage	2.6V
Number of Pins	2
LED Luminosity	90 mcd
Maximum Power Dissipation	78mW
Lens Dimensions	1 x 0.5 x 0.5 mm
Lens Shape	Rectangular

Key Features

The LED features a 1005 package and is designed for surface mounting.
Maximum forward current rating is 30 mA for reliable operation.
It has a clear, rectangular water-clear lens measuring 1 x 0.5 x 0.5 mm.
The device emits bright red light with an LED luminosity of 90 mcd.
Offers a wide viewing angle of 130 degrees for uniform light output.
Manufactured with RoHS compliant materials, ensuring environmental safety.
Features a two-pin connection and operates at a forward voltage of 2.6 V.
Ideal for electronic components, displays, indicator lights, and general lighting applications.

Product Description

Bivar SM0402RC 2.6 V Red LED 1005 Surface Mount is a compact, high-performance LED optimized for precise red light emission at 631nm wavelength. With a maximum power dissipation of 78 mW and a forward current capacity of 30 mA, this LED ensures energy-efficient operation in modern electronic circuits and display technologies.

This LED utilizes a standardized 1005 package with a surface mount design, enabling easy integration into printed circuit boards in industrial, automotive, and commercial electronics applications. The rectangular, water-clear lens measuring 1 x 0.5 x 0.5 mm provides excellent optical clarity and protection.

The 130-degree wide viewing angle delivers uniform illumination, making it suitable for indicator panels, signal lights, and small-scale lighting systems requiring consistent brightness and precise color rendering.

Manufactured under RoHS compliance, the SM0402RC meets environmental safety standards, appealing to manufacturers and designers focused on sustainable product development. The LED offers bright red color output with 90 mcd luminosity.

Compact dimensions facilitate use in dense PCB layouts and miniature electronic devices. Low forward voltage and controlled current ratings enhance energy efficiency. Standardized tape & reel packaging supports automated assembly and high-volume production.

Reliable electrical and mechanical specifications ensure long-term durability.

This product finds applications across various industrial segments including electronics manufacturing, instrumentation, automotive indicator systems, and general-purpose illumination solutions.

Explore more Bivar high-quality LEDs and other electronic components on EnvMart for complete solutions tailored to your project and production needs.
