FAG Self-Aligning 2 Row Ball Bearing 8 mm ID, 22 mm OD, 7 mm Race Width, Polyamide Cage 108-TVH-C3

FAG 108-TVH-C3 is a high-quality self-aligning ball bearing designed for industrial applications requiring reliable performance under radial and axial loads. This bearing features a double row configuration with a steel ball assembly and polyamide cage, ensuring durability and operational stability.

The bearing has an inside diameter of 8 mm, outside diameter of 22 mm, and a race width of 7 mm, making it suitable for a variety of mounting scenarios. It uses a parallel bore type and internal clearance C3 to allow for optimal alignment and reduced friction.

This self-retaining bearing design compensates for angular misalignments, offering smooth rotation and extended service life. The dynamic load rating of 2.75 kN and static load rating of 560 N ensure that the bearing can handle considerable loads in industrial, manufacturing, and mechanical machinery contexts.

The limiting speed of 39,000 rpm makes it viable for high-speed equipment, while the plain race design and TVH series construction provide precision and reliability. The polyamide cage offers excellent resistance to wear and helps in reducing noise and vibration during operation.

These bearings come in both open and sealed variants to suit different lubrication and environmental requirements. Typical applications include rotary bearings in mechanical machinery, power tools, HVAC systems, and manufacturing equipment.

Self-aligning ball bearing compensates for angular misalignments and ensures smooth operation. Double row construction supports both radial and axial loads effectively. Polyamide cage reduces noise and improves durability under operational stress.

High limiting speed rating of 39000 rpm enhances suitability for fast-moving machinery. Rated with internal clearance C3 for better thermal expansion compensation and speed. Steel balls enable strong load capacity and wear resistance for long service life.

Parallel bore type allows compatibility with various shaft types and adapter sleeves. TVH series design incorporates optimized raceway geometry for precision rotation. Available in open and sealed versions to meet lubrication and sealing demands.

Explore the range of FAG Ball Bearings for industrial, mechanical, and power tool applications on EnvMart for reliable sourcing and detailed technical support.
