Hongfa Europe GMBH PCB Power Relay 12V dc Coil 10A Switching Current DPST HF140FF/012-2HTF
Specifications
| Country of Origin | China |
|---|---|
| Brand | Hongfa Europe GMBH |
| Height | 26.3mm |
| Length | 29mm |
| Model | HF140FF/012-2HTF |
| Width | 13mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | HF140FF |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Contact Resistance | 50mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 275Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 530mW |
Key Features
- Operates with a coil voltage of 12V dc.
- Double-pole single-throw (DPST) contact configuration suitable for various switching requirements.
- Supports switching currents up to 10A for efficient power handling.
- Mounts on PCB with PCB pin terminals for secure electrical connections.
- Contains silver alloy contacts for enhanced conductivity and durability.
- Designed with a coil resistance of 275 ohms and coil power of 530mW.
- Operates within temperature range of -40°C to 85°C ensuring reliability under harsh conditions.
- Complies with RoHS standards for environmental safety.
Product Description
Hongfa Europe GMBH HF140FF/012-2HTF is a high-performance PCB power relay designed with a 12V dc coil and a 10A switching current capability in a DPST contact configuration. This relay is engineered for compact PCB mounting using PCB pin terminals, providing reliable electronic switching for industrial, automotive, and control applications.
The relay features silver alloy contacts that guarantee excellent conductivity and long operational life. It operates safely within a broad temperature range from -40°C to 85°C, making it suitable for demanding environmental conditions. The coil resistance of 275 ohms and coil power consumption of 530mW support efficient operation with minimal energy use.
Dimensionally, the relay is compact with a length of 29mm, width of 13mm, and height of 26.3mm, optimizing space on circuit boards. It meets RoHS standards ensuring it is environmentally friendly and compliant with current regulations. The isolation voltage of 5KV between coil and contacts enhances safety and reliability in electrical systems.
This power relay is widely used in automotive controls, industrial automation, and electronic devices requiring medium power switching capabilities. Its robust design and technical specifications make it ideal for controlling circuits that require 10A switched power with precision and safety.
Operates at a coil voltage of 12V dc for reliable switching. DPST contact configuration providing two independent switching paths. High switching current of 10A caters to various electronic load requirements. Compact PCB mount relay with PCB pin termination for straightforward installation.
Silver alloy contacts resist corrosion and maintain low contact resistance of 50mΩ. Wide operational temperature range from -40°C to 85°C for versatile applications. Designed with coil resistance of 275Ω and coil power of 530mW ensuring efficient operation.
Dimensions optimized for PCB design: 29mm x 13mm x 26.3mm (L x W x H). Conforms to RoHS standards for environmental and health safety compliance. Isolation voltage rated at 5KV between coil and contact enhances operational safety.
Explore EnvMart's extensive selections of electrical relays and components to meet your industrial and manufacturing needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum switching current of 10A, making it suitable for various electronic load requirements.
It operates with a coil voltage of 12V dc, ensuring reliable switching performance.
This relay features a double-pole single-throw (DPST) contact configuration, providing two independent switching paths.
The relay has dimensions of 29mm in length, 13mm in width, and 26.3mm in height, optimizing space on circuit boards.
The coil resistance is rated at 275 ohms, which supports efficient operation with minimal energy use.
It can operate safely within a temperature range from -40°C to 85°C, making it suitable for demanding environments.
This unit is designed for PCB mounting and utilizes PCB pin terminals for secure electrical connections.
The contacts are made of silver alloy, which enhances conductivity and durability.
The isolation voltage is rated at 5KV, enhancing safety and reliability in electrical systems.
It complies with RoHS standards, ensuring environmental safety and compliance with regulations.
The coil power consumption is rated at 530mW, which supports efficient operation.
It can switch DC voltages up to 30V and AC voltages up to 250V, suitable for various applications.
