TE Connectivity Heat Shrink Boot, Straight, LFH Polyolefin, Black, 36 mm 202K153-100-0
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Material | LFH Polyolefin |
| Colour | Black |
| Model | 202K153-100-0 |
| Series | 202K1 |
| Maximum Operating Temperature | 105°C |
| Dielectric strength | 15MV/m |
| Sub Type | Straight |
| Minimum Operating Temperature | -30°C |
| Number of Breakouts | 1 |
| Shrink Temperature | 100°C |
| Minimum Inside Diameter | 21mm |
| Maximum Shrunk Diameter | 22.4mm |
| Minimum Shrunk Diameter | 8.4mm |
| Maximum Inside Diameter | 36mm |
| TE Connectivity Straight 202A1 Black, Fluid Resistant Elastomer, 36.1 mmBrand | TE Connectivity |
| TE Connectivity Right Angle, 36mmBrand | TE Connectivity |
Key Features
- Constructed from zero halogen LFH Polyolefin for hazard reduction in fire events.
- Features low smoke, low emission properties enhancing safety in marine and transport applications.
- Operates between -30°C to 105°C with a shrink temperature of 100°C.
- Provides excellent sealing and strain relief with high dielectric strength of 15 MV/m.
- Designed for use with spin coupling backshells or suitable connector rear mounting.
- Meets DEF STAN 59/97 issue 3 Type DF standard for quality assurance.
Product Description
TE Connectivity 202K153-100-0 heat shrink boot is a straight sub-type heat shrink sleeve manufactured from low-smoke zero halogen (LFH) polyolefin material, providing critical safety features such as fire hazard reduction and low toxicity. This black heat shrink boot offers a minimum inside diameter of 21 mm and a maximum inside diameter of 36 mm, with a shrink temperature rated at 100°C. It operates reliably in temperature ranges from -30°C to a maximum of 105°C.
Widely utilized in stringent environments such as marine, transport, and offshore industries, the boot is designed to deliver superior dielectric strength of 15 MV/m, providing excellent electrical insulation. Its low smoke and low emission characteristics comply with safety indexes NES711, NES713, and NES715, making it suitable for applications where toxic fumes and smoke emissions must be minimized.
The boots provide robust sealing and strain relief capabilities, ensuring secure cable connections under demanding operational conditions. Although adhesive backing is not provided, the boot is compatible with sealant kits (note: kits do not maintain zero halogen properties). The 202K1 series conform to DEF STAN 59/97 issue 3 Type DF certification, ensuring material and performance consistency.
Package includes a single breakout heat shrink boot, measuring 36 mm in diameter overall. It can be used effectively with spin coupling backshells or other connectors offering rear mounting solutions. The black coloration provides easy visual identification and is suitable for various industrial wiring and installation needs.
This product is perfectly suited for electrical, automation, and cable applications requiring reliable insulation and environmental protection in industrial, manufacturing, and commercial settings.
Constructed from zero halogen LFH polyolefin for fire safety. Low smoke and low emission properties for hazardous environment use. Temperature tolerance from -30°C to 105°C. Dielectric strength rated at 15 MV/m. Compatible with spin coupling backshells and rear mounting connectors.
Explore our range of TE Connectivity Heat Shrink Boots and cable solutions on EnvMart for high-quality cable protection components suitable for professional applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this heat shrink boot is 105°C.
This model has a dielectric strength rated at 15 MV/m.
The minimum inside diameter of the heat shrink boot is 21 mm.
It operates reliably in a temperature range from -30°C to 105°C.
The shrink temperature for this heat shrink boot is 100°C.
It is constructed from low-smoke zero halogen (LFH) polyolefin material.
This heat shrink boot is suitable for use in marine, transport, and offshore industries, providing insulation and environmental protection.
This model has one breakout.
The maximum inside diameter of the heat shrink boot is 36 mm.
No, adhesive backing is not provided, but it is compatible with sealant kits.
It conforms to DEF STAN 59/97 issue 3 Type DF certification for quality assurance.
The heat shrink boot is black in color, allowing for easy visual identification.
