ABB XT4S Molded Case Circuit Breaker 4-Pole 80A 690V AC 500V DC Thermal Magnetic Lever Actuator XT4S

Free Delivery in India | Lowest Global Shipping Charges

ABB XT4S Molded Case Circuit Breaker 4-Pole 80A 690V AC 500V DC Thermal Magnetic Lever Actuator XT4S



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT4S
Brand	ABB
Height	160mm
Model	XT4S
Depth	82.5mm
Width	140mm
Mount Type	Fixed
Current Rating	80A
Series	XT4S
Terminal type	Fixed
Breaking Capacity	85kA
Number of Poles	4
Standards/Approvals	CE, IEC, RoHS
Rated AC Voltage	690V ac
Rated DC Voltage	500V dc
Better World Claim	Designed for Disassembly
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Lever
Short circuit performance level	S

Key Features

Rated for 80 amperes current load with 4 poles for multiphase power distribution.
Breaking capacity up to 85 kiloamperes to safely interrupt fault currents.
Designed for fixed mounting with front terminals for secure installation.
Operates on rated AC voltage of 690 volts and DC voltage rating of 500 volts.
Equipped with a lever type reset actuator for easy manual operation.
Thermal magnetic tripping mechanism provides protection against overloads and short circuits.
Compact dimensions with height 160 mm, width 140 mm, and depth 82.5 mm for efficient panel fit.
Conforms to CE, IEC, and RoHS standards ensuring quality and compliance.

Product Description

ABB XT4S Molded Case Circuit Breaker model XT4S is a high-performance fixed 4-pole circuit breaker rated for 80 amperes. It is engineered with a thermal magnetic tripping mechanism that provides robust protection against overload and short circuit conditions in industrial and commercial electrical installations.

This breaker supports a maximum breaking capacity of 85 kiloamperes, ensuring reliable interruption of high fault currents. The rated AC voltage is 690 V, and the rated DC voltage is 500 V, making it suitable for diverse power distribution applications.

The device features front terminals for secure and straightforward wiring connections and a lever-type reset actuator for convenient manual reset operations. Its compact form factor with dimensions of 160 mm in height, 140 mm in width, and 82.5 mm in depth allows efficient use of panel space.

ABB XT4S complies with international standards CE, IEC, and RoHS, underscoring its quality and environmental responsibility. Notably, it is a Better World product, designed specifically for disassembly which contributes to sustainability goals.

This circuit breaker is ideal for industrial electrical distribution systems requiring dependable protection and ease of maintenance. It is predominantly used in power distribution panels, automation setups, and industrial machinery circuits.

Rated current of 80 A for dependable power management. Four poles for multiphase electrical circuits. Breaking capacity of 85 kA for fault current interruption. Thermal magnetic tripping ensures protection against electrical faults.

Reliable lever reset actuator for manual control. Compact size suitable for installation in electrical panels. Conforms to CE, IEC, and RoHS standards for safety and sustainability. Designed and manufactured in Italy, reflecting premium manufacturing standards.
