SICK Retroreflective Photoelectric Sensor Block Sensor 4.5 m Detection Range NPN Output IP67 RAY26P-24162330A00

Free Delivery in India | Lowest Global Shipping Charges

SICK Retroreflective Photoelectric Sensor Block Sensor 4.5 m Detection Range NPN Output IP67 RAY26P-24162330A00

Name: SICK Retroreflective Photoelectric Sensor Block Sensor 4.5 m Detection Range NPN Output IP67 RAY26P-24162330A00
Brand: SICK
SKU: 402017
Price: 637.29 USD
Availability: InStock



Category Photoelectric Sensor Brand SICK Condition New

Specifications

Country of Origin	Germany
Brand	SICK
Response time	3ms
Light Source	LED
Detection range	4.5 m
Model	RAY26P-24162330A00
IP Rating	IP67
Mount Type	Screw
Housing Material	Plastic
Output type	NPN
Series	Reflex Array
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-40°C
Maximum Current	100mA
DetectIon Type	Retroreflective
Terminal type	4-Pin Connector
Interface Type	IO-Link
Maximum dc Voltage	30V dc
Standards/Approvals	UL File No. NRKH.E181493 & NRKH7.E181493
Sensor Style	Block
RAY10	25 mm-high light array, detects objects ≥ 5 mm
RAY26	55 mm-high light array, three variants, detects objects ≥ 3 mm, ≥ 5 mm or ≥ 10 mm
Conveyor belt suppression	Manual or via IO-Link

Key Features

Designed for reliable detection of small, flat, transparent, or unevenly formed objects using a reflex array light array.
Features a 55 mm-high light array with variants detecting objects ≥ 3 mm, ≥ 5 mm, or ≥ 10 mm.
Equipped with IO-Link interface for communication and predictive maintenance support.
Robust IP67-rated plastic housing suitable for industrial environments.
Operates with LED light source and supports conveyor belt suppression manual or via IO-Link.
Fast response time of 3 milliseconds for quick sensing applications.
Wide operating temperature range from -40°C to +60°C.
Supports screw mounting for secure and flexible installation.

Product Description

The SICK RAY26P-24162330A00 Retroreflective Photoelectric Sensor is a block sensor designed for industrial automation and control applications. Featuring a 4.5 m detection range and NPN output type, this sensor precisely detects objects such as glass bottles, polybags, flat boards, pallets, and profile wood panels on conveyor belts utilizing a reflex array light array.

Its 55 mm-high light array detects objects sized as small as 3 mm, 5 mm, or 10 mm depending on the variant. Equipped with an LED light source and IO-Link communication interface, it enables predictive maintenance through auto-adapt functionality and transmits maintenance signals to programmable logic controllers.

The sensor housing is constructed of durable plastic and rated IP67 for dust and water protection, supporting installation via screw mount. It supports conveyor belt suppression manually or through IO-Link to reduce false triggering from belt movement. With a fast response time of 3 ms and a wide operating temperature range from -40°C to 60°C, the sensor is highly reliable in various industrial and manufacturing environments.

Applications include feeder clip monitoring, terminal monitoring, leading edge detection, polybag detection, and PCB buffer store detection. The sensor's ability to detect perforated objects reduces switching errors and commissioning time, enhancing operational efficiency and cost savings.

Reliable detection of small and uneven objects on conveyor belts. High sensitivity with multiple detection size options. IO-Link enables advanced diagnostic and maintenance features. Robust IP67-rated plastic housing for harsh environments.

Fast switching response for high-speed applications. Flexible mounting options with screw mount. Conveyor belt suppression options to minimize false signals. Wide temperature capability for various industrial conditions.

Boosts operational efficiency and reduces maintenance downtime.

This sensor is manufactured in Germany, reflecting high quality standards. It fits well within industrial automation, manufacturing, and material handling categories. Explore more sensors in the SICK product range at EnvMart for reliable automation solutions.
