Yageo 22 nF Multilayer Ceramic Capacitor 50V DC ±10% Tolerance Surface Mount 0603 Case CC0603KRX7R9BB223

Yageo CC0603KRX7R9BB223 multilayer ceramic capacitor provides 22 nF capacitance, suitable for surface mount technology (SMT) applications demanding compact and reliable passive components. Rated for 50V DC with ±10% tolerance, this capacitor leverages an X7R dielectric, ensuring consistent performance across a broad temperature range from -55°C to 125°C.

The 0603 package size, measuring 1.6mm length, 0.8mm width, and 0.8mm height, makes it ideal for space-constrained electronic assemblies including PCs, hard disk drives, game consoles, power supplies, DVD players, and mobile phones. It features a nickel barrier end termination that supports lead-free soldering processes and complies with RoHS and Halogen Free directives, promoting environmentally responsible manufacturing.

Standard compliant as per IEC 60384 series, this capacitor assures industrial-grade quality suitable for demanding electronic circuits. Supplied in paper/PE tape reel packaging, it supports automated pick-and-place equipment for high-volume production environments.

Compact 0603 case size supports high-density PCB layouts. Stacked construction enhances capacitance stability and reliability. X7R dielectric material delivers stable temperature performance. Operating temperature range from -55°C up to 125°C.

RoHS and Halogen Free compliant for environmentally friendly manufacturing. Nickel barrier end termination suitable for lead-free soldering. Meets IEC 60384-21/22 and IEC 60384-1 international standards. Packaged in tape reel for streamlined automated assembly.

This Multilayer Ceramic Capacitor is widely used in industrial, electronics manufacturing, consumer electronics, telecommunications, and computing applications where compact size and reliability are critical. EnvMart customers may explore this series for efficient solutions in passive component design and inventory.
