LPRS RF Module FM Narrow Band Modulation 458.775 MHz 12V LC-TX458E-R
Specifications
| Country of Origin | Japan |
|---|---|
| Frequency | 458.775MHz |
| Brand | LPRS |
| Height | 1mm |
| Length | 30mm |
| Model | LC-TX458E-R |
| Mount Type | Embedded |
| Series | CDP-TX/RX-02E-R |
| Maximum Operating Temperature | 60°C |
| Sub Type | Transmitter/Receiver |
| Minimum Operating Temperature | -20°C |
| Component Type | Module |
| Receiver Sensitivity | -120dBm |
| Maximum Output Power | 10mW |
| Standards/Approvals | RoHS, EN 300 220, R&TTE (EN 300 220) |
| Maximum Supply Voltage | 12V |
| Minimum Supply Voltage | 3V |
| Modulation Technique | FM narrow band modulation |
| Maximum RF Data Rate | 4800bps |
Key Features
- This module provides narrowband FM modulation for reliable communication.
- Operates at a maximum RF data rate of 4800bps with a frequency of 458.775 MHz.
- Maximum output power of 10mW supports long range transmissions up to 1000 meters.
- Receiver sensitivity is -120dBm to ensure clear signal reception.
- Compatible with TTL/CMOS logic levels and frequency selection available on 11 channels.
- Compact embedded mount type with dimensions of 30mm length and 1mm height.
- Operates safely within a temperature range from -20°C to 60°C.
- Compliant with RoHS, EN 300 220 and R&TTE standards for regulatory conformance.
Product Description
LPRS LC-TX458E-R is an RF module featuring FM narrow band modulation technology operating at a frequency of 458.775 MHz with a supply voltage of 12V. This transmitter module supports efficient wireless data transmission with a maximum RF data rate of 4800bps. It is designed to function reliably over distances up to 1000 meters, suitable for industrial, telemetry, and remote control applications.
The module employs narrowband FM modulation to ensure robust and interference-resistant communications, compatible with TTL/CMOS logic for ease of integration into various embedded systems. Its compact embedded form factor with a length of 30mm and height of 1mm facilitates seamless installation in constrained spaces.
Operating temperature ranges from -20°C to 60°C make it viable for use in diverse environmental conditions. Certified to RoHS, EN 300 220, and R&TTE standards, the module meets international regulatory requirements ensuring safe and legal deployment.
The LPRS LC-TX458E-R module is ideal for applications involving telemetry, data transmission, room surveillance, and other wireless communication needs in industrial, manufacturing, and commercial sectors.
This module provides narrowband FM modulation for reliable communication. Operates at a maximum RF data rate of 4800bps with a frequency of 458.775 MHz. Maximum output power of 10mW supports long range transmissions up to 1000 meters.
Receiver sensitivity is -120dBm to ensure clear signal reception. Compatible with TTL/CMOS logic levels and frequency selection available on 11 channels. Compact embedded mount type with dimensions of 30mm length and 1mm height.
Operates safely within a temperature range from -20°C to 60°C. Compliant with RoHS, EN 300 220 and R&TTE standards for regulatory conformance. Ideal for telemetry, data transmission, room surveillance, and general wireless applications.
Designed and manufactured in Japan ensuring high-quality standards. Explore more RF modules from LPRS and discover reliable wireless solutions for your electronic design and industrial communication systems at EnvMart.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This module operates at a frequency of 458.775 MHz, allowing for effective wireless communication.
It supports a maximum RF data rate of 4800bps, enabling efficient data transmission.
The receiver sensitivity is -120dBm, which ensures clear signal reception.
This model has dimensions of 30mm in length and 1mm in height, making it compact for embedded applications.
It operates safely within a temperature range from -20°C to 60°C, suitable for various environmental conditions.
It employs FM narrow band modulation for reliable communication.
Yes, it is compatible with TTL/CMOS logic levels, facilitating easy integration into embedded systems.
It is compliant with RoHS, EN 300 220, and R&TTE standards, ensuring regulatory conformance.
This unit features an embedded mount type, allowing for seamless installation in constrained spaces.
The minimum supply voltage required for operation is 3V, while the maximum is 12V.
