ABB Modular DIN Rail Electronic Circuit Breaker 10A 24V Current Limitation 1.8 x IN EPD24

ABB EPD24 Electronic Circuit Breaker is a high-quality modular DIN rail component designed for precise overcurrent protection of 24V DC load circuits in industrial, automation, electrical, and manufacturing applications.

The EPD24 series utilizes advanced electronic protection techniques to limit current during short circuits and overload conditions, rapidly disabling power output transistors to interrupt faulty current flows.

This model delivers a current rating of 10A and features complex tripping characteristics with current limitation of 1.8 x IN for currents between 0.5 to 6A, 1.5 x IN for 8 to 10A, and quick electronic release trip times ranging from 100 milliseconds to 3 seconds when the load exceeds configured thresholds.

The device is easy to install via DIN rail mounting and offers space-saving dimensions of 12.5 mm width, 83 mm length, and 83 mm depth. Terminals use screw connection types for secure wiring.

Users benefit from a manual ON/OFF button, clear LED status indicators, and an integrated auxiliary contact that enhances system monitoring and fault indication. The breaker supports capacitive load activation up to 20,000 microfarads making it compatible with various electronic loads and complex industrial circuits.

Manufactured in Germany, the product complies with RoHS directive and UL/CSA safety approvals ensuring reliable industrial-grade performance. Designed for modular DIN rail mounting in industrial and automation systems. Features current limitation at 1.8 times the rated input from 0.5A to 6A.

Trip characteristics include 1.5 x IN for 8-10A and electronic release trip times of 100 ms to 3 s over current load. Includes manual ON/OFF button for operational control. LED status indicators and integrated auxiliary contact simplify monitoring and fault diagnosis.

Accommodates capacitive loads up to 20,000 μF ensuring suitability with electronic loads. Compact design with only 12.5 mm width enables space-saving installations. Robust screw terminal connections ensure secure wiring.

Complies with RoHS, UL, and CSA standards for safety and environmental compliance.

Suitable for use in industrial electrical panels, automated manufacturing processes, water treatment plants, HVAC control systems, and laboratory equipment, the ABB EPD24 circuit breaker offers dependable overcurrent protection where precise electronic control is critical.
