nVent SCHROFF 1 U 19 in Rack Mount Case Steel Frame Grey Aluminium Front Panel Interscale M 177 mm x 221 mm x 44 mm 14820154

nVent SCHROFF model 14820154 is a 1 U 19 inch rack mount case from the Interscale M series, featuring a robust steel frame with a grey finish and aluminium front and rear panels. It is designed for housing electronic assemblies in various industrial, laboratory, commercial, and HVAC applications. The enclosure provides IP30 ingress protection and integral electromagnetic compatibility shielding (EMC), making it suitable for sensitive electronic modules and systems.

The external dimensions of this rack mount case are 177 mm depth, 221 mm width, and 44 mm height, conforming to a standard 1 U rack unit size. The Interscale M series cases are modular and versatile with quick assembly/disassembly using just two screws, facilitating ease of maintenance and installation. The panels are removable for rapid access to internal components.

This enclosure series supports multiple configurations with options for perforated or solid side panels; this model includes solid panels ensuring IP30 protection. Its sturdy Al Zn-coated steel body is powder-coated in RAL7016 grey, providing corrosion resistance and a professional industrial look. Aluminium front and rear panels allow for easy modifications such as cutouts or connector mounting.

Applications include fan-free fieldbus enclosures, embedded systems like single-board computers and ARM modules, medical diagnostic equipment, PC-based point-of-sale (POS) systems, video surveillance systems, and peripheral control units in industrial automation.

Accessories compatible with the Interscale M series include mounting plates, fan units, PCB supports, assembly tools, DIN rail clips, and adhesive bases for PCB mounting, enhancing installation flexibility.

This product is supplied with a base, two side panels (solid), a top cover, front and rear panels, the assembly kit, and a user manual, providing a complete enclosure system ready for electronic housing deployment.

Explore the extensive range of industrial electronic enclosures and discover compatible accessories and complementary products suitable for your application at EnvMart. The case features a durable steel body with aluminium front and rear panels.

External dimensions are 177 mm depth, 221 mm width, and 44 mm height (1U rack unit). Provides IP30 protection with solid side panels for safe housing of electronic components. The modular Interscale M series offers easy assembly and disassembly with only two screws.

Integral EMC protection ensures interference shielding up to approximately 20 dB at 2 GHz. Suitable for 19 inch rack mounting and desktop applications, also DIN rail mountable with accessory. Applications include fieldbus enclosures, single-board computers, medical diagnostic devices, POS systems, video monitoring, and industrial control peripherals.

Finished with a fine powder coating in RAL7016 grey for professional appearance and corrosion resistance. Supplied complete with base, two side panels (solid), top cover, front and rear panels, assembly kit, and user manual.
