MikroElektronika Capacitive Touch LCD Module for Desktop or Notebook Computer Control MIKROE-2964

MikroElektronika MIKROE-2964 Capacitive Touch LCD Module is designed for desktop or notebook computer control and various consumer electronics and home appliances. It serves as an advanced human-machine interface (HMI) development tool featuring capacitive touch technology for precise and customizable user interaction.

This LCD module includes six capacitive touch sensor inputs with programmable sensitivity, automatic recalibration, and individual button threshold adjustments ensuring robustness in different environments. It supports proximity detection and multiple button pattern detection to enhance interface flexibility.

Communication is versatile with SMBus/I2C compliant interface, SMSC BC-Link, SPI communications, and pin-selectable communication protocols allowing integration with multiple systems. The module operates with low power consumption, featuring a deep sleep mode at 5 microamps quiescent current and standby mode at 50 microamps with one sensor monitored.

Additional features include six LED driver outputs capable of open drain or push-pull operation, programmable blink, breathe, and dimness controls, and a dedicated wake output flagging touch events even in low power states. The system reset pin adds to reliability during operation.

The module is housed in compact 20-pin 4mm x 4mm QFN or 24-pin SSOP packages facilitating easy PCB integration. It complies with RoHS standards and is suited for industrial, laboratory, consumer electronic, and commercial applications requiring advanced capacitive touch HMI solutions.

Features six capacitive touch sensor inputs with programmable sensitivity. Supports proximity detection and multiple button pattern detection. Includes automatic recalibration and press and hold feature for volume control applications.

Offers multiple communication interfaces including SMBus/I2C and SPI with pin-selectable protocols. Low power consumption with 5uA quiescent current in deep sleep. Includes six LED driver outputs with programmable blink, breathe, and dimness controls.

Available in 20-pin 4mm x 4mm QFN or 24-pin SSOP package options.

This MikroElektronika capacitive touch LCD module is an essential component in applications involving desktop and notebook PCs, LCD monitors, and various home appliances requiring precise capacitive touch interfaces. It meets the demands of electronic development tools for HMI and enhances the user experience in consumer electronic products.
