Molex Micro-Fit 3.0 Series Straight Surface PCB Header, 4 Contact, 3 mm Pitch, 1 Row, Shrouded 43650-0421
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250V |
| Brand | Molex |
| Orientation | Straight |
| Current | 5A |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | Micro-Fit 3.0 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 3mm |
| Contact Plating | Tin |
| Number of Contacts | 4 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Supports up to 5A current in a small footprint for efficient power distribution.
- Constructed with thermoplastic housing and brass contacts with tin plating for durability.
- Features positive latching with a locking ramp to prevent accidental disconnection.
- Designed for surface mount with solder termination and metal press-fit retention clips.
- Wide operating temperature range from -40°C up to 105°C for robust performance.
- High temperature UL94V-0 liquid crystal polymer housing withstands up to 265°C during IR reflow soldering.
- Applications include military COTS, solar power, consumer electronics, data communications, medical, and telecommunications.
Product Description
Molex Micro-Fit 3.0 Series PCB Header model 43650-0421 is a high-performance 4-contact wire-to-board connector with a 3 mm pitch and single row, shrouded configuration designed for surface mounting. It is engineered to provide a reliable low to mid-range power distribution solution with a current capacity of 5A.
This header features thermoplastic housing and brass contacts plated with tin, ensuring durable electrical connections. The connector incorporates positive latching via a locking ramp on the housing to provide secure mating and to prevent accidental disconnection during operation.
The housing material is a high-temperature UL94V-0 liquid crystal polymer, capable of withstanding temperatures up to 265°C during infrared reflow soldering processes, making it suitable for modern PCB manufacturing techniques. The solder termination type combined with metal press-fit retention clips ensures secure mechanical attachment to PCB surfaces, reducing process costs and enhancing reliability.
Operating temperature ranges from -40°C to 105°C, supporting applications in harsh environments. The contacts are fully isolated within the housing to minimize electrical arcing, improving safety and durability.
Typical industrial and commercial applications include military commercial off-the-shelf (COTS) solutions, solar energy systems, consumer electronics, data communication devices, medical equipment, telecommunications infrastructure, and gaming terminals.
Supports up to 5A current in compact design. High-temperature thermoplastic housing for advanced soldering. Positive latching mechanism for secure connections. Solder termination with press-fit retention for reliability.
Wide operating temperature from -40°C to 105°C. Fully isolated contacts to prevent arcing. Suitable for diverse industrial and commercial uses. Explore the Molex range for high-quality PCB headers and connectors at EnvMart for your electronic and power connector needs.
Explore more products in our PCB Connectors & Wire Housings category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current capacity of up to 5A, making it suitable for low to mid-range power distribution applications.
The pitch of this connector is 3 mm, which is designed for efficient space utilization on PCBs.
It features a solder termination type, ensuring secure connections to the PCB.
The maximum operating temperature for this PCB header is 105°C, allowing it to perform in various environments.
The housing is made of thermoplastic, while the contacts are brass with tin plating for enhanced electrical connection durability.
Yes, this model is specifically designed for surface mount applications with solder termination and metal press-fit retention clips.
It is suitable for various applications including military COTS, solar power, consumer electronics, data communications, medical, and telecommunications.
This PCB header has 4 contacts, providing multiple connection points for efficient power distribution.
The orientation of this model is straight, allowing for straightforward integration into PCB designs.
The minimum operating temperature is -40°C, enabling its use in harsh environmental conditions.
It utilizes a wire-to-board connector system, facilitating direct connections between wires and the PCB.
The country of origin for this PCB header is India, indicating its manufacturing location.
