Socomec 1 Phase Energy Meter LCD Display Countis E00 Series 48503058

Socomec 48503058 1 Phase Energy Meter from the Countis E00 Series is a highly accurate device equipped with an easy-to-read LCD display featuring 7 digits for comprehensive energy consumption monitoring.

This energy meter allows direct connection up to 32/40 A, making it suitable for residential, commercial, and industrial electrical systems.

The meter is certified to international standards including Class 1 accuracy according to IEC 62053-21, Class B as per EN 50470, and Class 2 compliance under IEC 62053-22, ensuring reliable performance.

It supports pulse output functionality with 5 outputs enabling detailed data integration with automation and energy management systems. Operating temperature ranges from -25°C to 55°C, allowing deployment in diverse environmental conditions.

Compact dimensions with a 90mm height and 18mm width cutout, 64mm depth, and an 85mm digit height provide easy installation and readability in panels.

This energy meter is designed for industrial, manufacturing, HVAC, commercial electrical systems, and utility monitoring applications requiring precise energy measurement and reporting.

Features a clear LCD type display with 7 digits for easy reading. Designed for direct connection up to 32/40 A. High accuracy with Class 1 (IEC 62053-21), Class B (EN 50470), and Class 2 (IEC 62053-22) standards. Supports pulse output and has 5 outputs for detailed measurement data.

Operates within -25°C to 55°C temperature range, suitable for various environments. Compact design with cutout dimensions 90mm height and 18mm width, depth of 64mm. Digit height of 85mm ensures visibility in control panels and installations.

Modular design ideal for industrial and commercial electrical energy monitoring applications. Explore more Energy Meters and control devices in EnvMart’s industrial measurement category.
