Monacor RS PRO Analogue Panel Ammeter 50 A DC, 57 mm x 44 mm, ±1.5 % Accuracy, High Torque Pivot and Jewel Moving 186-2535

Monacor 186-2535 RS PRO Analogue Panel Ammeter is a reliable 50 A DC current meter designed for professional electrical monitoring and control applications. Featuring a high torque pivot and jewel moving coil with moving iron mechanism, the ammeter delivers precise readings with ±1.5% accuracy. The robust design includes a clear polycarbonate cover and a detachable lower fascia plate for flexible installation and maintenance.

The panel cut-out size is 57 mm height by 44 mm width and the overall depth is 45.7 mm, making it compatible with standard panel sizes. The knife-edge type pointer and rear zero adjuster enhance usability and accuracy adjustment capabilities. It functions reliably within the ambient temperature range of 0°C to 60°C with relative humidity levels from 25% to 80%.

This ammeter supports maximum measurement parameters of 600 V at 65 Hz and can handle up to 1000 A for AC signal compatibility. It is ideal for use in marine environments, switchgear assemblies, distribution systems, embedded generation, energy management, building automation, control panels, motor monitoring, and utility power monitoring systems.

The product fully complies with internationally recognized standards such as UL 3111-1, ISO 20653:2006-08, DIN 43807, UL 94 V-O, IEC 61010-1, EN 61010-1, IEC 529, and others, ensuring quality and safety in diverse industrial and commercial environments.

The ammeter operates with high torque pivot and jewel moving coil and moving iron elements. Dimensions include a 57 mm height cut-out and 44 mm width cut-out with 45.7 mm depth. It operates accurately between 0°C to 60°C ambient temperature.

The meter features a knife-edge type pointer and rear zero adjuster for user calibration. The design supports a maximum measurement of 600 V at 65 Hz and 1000 A. Relative humidity operation range is 25% to 80%. The unit is enclosed in a durable polycarbonate cover with a detachable lower fascia plate.

Applications include marine, switchgear, control panels, energy management, and utility power monitoring. This product meets multiple international standards and certifications including UL, IEC, and CE. Shop Monacor products and related industrial electrical instruments on EnvMart for expert solutions in automation and control gear.
