ABB Molded Case Circuit Breaker 4-Pole 160A Breaking Capacity 150 kA Fixed Rated AC Voltage 690V AC XT2L

Free Delivery in India | Lowest Global Shipping Charges

ABB Molded Case Circuit Breaker 4-Pole 160A Breaking Capacity 150 kA Fixed Rated AC Voltage 690V AC XT2L



Category Molded Case Circuit Breaker Brand ABB Condition New

Specifications

Country of Origin	Italy
Range	XT2L
Brand	ABB
Height	130mm
Model	XT2L
Depth	82.5mm
Width	120mm
Mount Type	Fixed
Current Rating	160A
Series	1SDA06
Terminal type	Fixed
Breaking Capacity	150kA
Number of Poles	4
Standards/Approvals	RoHS, CE, IEC
Rated AC Voltage	690V ac
Better World Claim	Designed for Disassembly
Tripping Mechanism	Solid State
Reset Actuator Type	Lever
Short circuit performance level	L

Key Features

Current rating of 160A for reliable electrical protection.
Breaking capacity of 150 kA ensures high short circuit performance.
Fixed mounting type with fixed terminals for secure installation.
Operates at a rated AC voltage of 690V with 1000V insulation voltage.
Solid state tripping mechanism for precise and consistent operation.
Complies with RoHS, CE, and IEC standards for safety and environmental compliance.
Equipped with lever-type reset actuator for easy manual control.
Designed for disassembly supporting sustainable use and maintenance.

Product Description

ABB XT2L Molded Case Circuit Breaker 4-Pole 160A is engineered for high-performance protection in electrical distribution systems. This fixed-mount circuit breaker supports operational AC voltages up to 690V and insulation voltages of 1000V, making it suitable for demanding industrial, manufacturing, and commercial applications. The breaker features a solid state release mechanism (Ekip I) delivering precise tripping and enhanced operational reliability.

With a breaking capacity of 150 kA and a short circuit performance level of L, this device safeguards electrical circuits against severe fault conditions, thereby minimizing downtime and potential equipment damage. The 4-pole configuration and fully rated neutral contribute to its effectiveness in three-phase systems.

Compliant with international standards including RoHS, CE, and IEC, the ABB XT2L circuit breaker ensures environmental and safety adherence. Its compact form factor, with dimensions of 120mm width, 130mm height, and 82.5mm depth, fits a variety of panel sizes while supporting easy installation through fixed terminals.

The lever-type reset actuator provides convenient manual control, allowing quick resets after fault clearance. The design supports disassembly, contributing to sustainability by facilitating maintenance and recycling practices.

This molded case circuit breaker is ideally suited for electrical, automation, HVAC, manufacturing, and commercial industrial sectors requiring dependable circuit protection and operational safety.

Current rating of 160A ensures reliable circuit protection. Breaking capacity of 150 kA offers robust short circuit interruption capability. Fixed mounting with fixed terminals guarantees secure installation. Compliance with RoHS, CE, and IEC standards promotes safety and environmental responsibility.

Compact dimensions allow integration into diverse electrical panels. Solid state release mechanism enhances operational accuracy. Lever reset actuator facilitates user-friendly manual operation. Designed for disassembly, supporting sustainable product lifecycle.

Explore ABB and related circuit breaker products in the Molded Case Circuit Breaker category on EnvMart for compatible electrical protection solutions.
